GBU1001
THRU
GBU1007
Single Phase 10.0 AMPS. Glass Passivated Bridge Rectifiers
Voltage Range
50 to 1000 Volts
Current
10.0 Amperes
Features
UL Recognized File # E-96005
Ideal for printed circuit board
Reliable low cost construction
Plastic material has Underwriters Laboratory
Flammability Classification 94V-0
Surge overload rating to 200 amperes peak
High temperature soldering guaranteed:
260
O
C / 10 seconds / .375鈥? (9.5mm) lead
lengths.
GBU
.020R(TYP.)
.310(7.90)
.290(7.40)
.160(4.1)
.140(3.5)
.880(22.3)
.860(21.8)
0.125(3.2)x45
CHAMFER
.740(18.8)
.720(18.3)
.140(3.56)
.130(3.30)
9
TYP.
.085(2.16)
.065(1.65)
.075
(1.9)R
.080(2.03)
.060(1.52)
Mechanical Data
Case: Molded plastic body.
Terminals: Plated leads solderable per
MIL-STD-750, Method 2026.
Weight: 0. 3 ounce, 8.0 grams
Mounting torque: 5 in. lb. Max.
.100(2.54)
.085(2.16)
.050(1.27)
.040(1.02)
.190(4.83)
.210(5.33)
.710(18.0)
.690(17.5)
.085(2.16)
.075(1.90)
.080(2.03)
.065(1.65)
.022(0.56)
.018(0.46)
Dimensions in inches and (millimeters)
Maximum Ratings and Electrical Characteristics
Rating at 25鈩僡mbient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Symbol GBU GBU
Type Number
1001 1002
Maximum Recurrent Peak Reverse Voltage
50 100
V
RRM
Maximum RMS Voltage
35
70
V
RMS
Maximum DC Blocking Voltage
50 100
V
DC
Maximum Average Forward Rectified Current
@T
C
= 100鈩?/div>
Peak Forward Surge Current, 8.3 ms Single
Half Sine-wave Superimposed on Rated
Load (JEDEC method )
Maximum Instantaneous Forward Voltage
@ 10.0A
Maximum DC Reverse Current @ T
A
=25鈩?/div>
at Rated DC Blocking Voltage @ T
A
=125鈩?/div>
Typical Thermal Resistance Per Leg
(Note 1)
(Note 2)
GBU GBU GBU GBU GBU
Units
1003 1004 1005 1006 1007
200
140
200
400
280
400
10.0
220
1.1
5.0
500
21.0
2.0
600
420
600
800 1000
560 700
800 1000
V
V
V
A
A
V
uA
uA
鈩?W
I
(AV)
I
FSM
V
F
I
R
R
胃
JA
R
胃
JC
Cj
T
J
Typical Junction Capacitance (Note 3)
Operating Temperature Range
Storage Temperature Range
211
-55 to +150
-55 to + 150
94
T
STG
Notes 1: Units Mounted In Free Air No Heat Sink On PCB 0.5x0.5 鈥?(12x12mm) Copper Pads,
0.375鈥?9.5mm) Lead Length.
2: Device Mounted on 4鈥?x 6鈥?x 0.25鈥?Al-Plate Heatsink.
3. Measured at 1.0 MHZ and applied Reverse Voltage of 4.0V.
pF
