Under development
New product
GA102T1M2MZ
Features
( 1 ) DVD-R/RW,+R/RW : 4脳 speed writing
( 2 ) OPIC light detector
(PIN photodiode and IC onto single device)
( 3 ) Can control the sensitivity by external resistance
( 4 ) Surface mount-leadless package
(Package dimensions: 5.0
脳
4.0
脳
1.295mm)
( 5 ) Applicable for reflow
OPIC Light Detector
*
OPIC Light Detector for 4脳 Speed Writing DVD-R/RW,+R/RW power monitor
Outline Dimensions
4.0
3.5
0.4
(Unit:mm)
6
Detector
Center
5
4
0.7
3.6
5.0
2.0
0.895
P 1.25
1
2
3
Applications
Terminal configuration
( 1 ) DVD-R/RW drives
( 2 ) DVD+R/RW drives
( 3 ) DVD-ROM drives
1
2
3
4
5
6
V
CC
V
REF
GND
V
R
IN
R
REF
*
Specifications
"OPIC" (Optical IC) is a trademark of SHARP Corporation.
An OPIC consists of a light-detecting element and a signal-processing
circuit integrated onto a single chip.
1.295
(Ta=25藲C)
Parameter
Supply voltage
Supply current
Output off-set voltage
Sensitivity 1
Sensitivity 2
Response frequency
Maximum output voltage
Settling time
Operating temperature
Symbol
Vcc
Icc
Vod
R
P1
R
P2
fc
V
OH
Characteristics
4.5 to 5.5 V
TYP. 12 mA
鹵
19 mV
TYP.
4.8
mV/碌W
TYP.
6.0
mV/碌W
MIN. 30 MHz
TYP. 4.0 V
TYP. 30 ns
0 to + 70藲C
Condition
鈭?/div>
Under light shielding
鈭?/div>
位=650nm
位=780nm
位=650nm,780nm,
-3dB
位=650nm,780nm
位=650nm,780nm,
Vo=1V to
鹵10mV
鈭?/div>
t
set
Topr
(Notice)
鈥n the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment
using any SHARP devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before
using any SHARP device.
鈥pecifications are subject to change without notice for improvement.
(Internet)
鈥ata for Sharp's optoelectronic/power devices is provided on internet. (Address http://sharp-world.com/ecg/)
1/2
D1-020901
