GA102T1M1MZ
Features
( 1 ) CD-R/RW : 16脳 to 20脳 speed writing
( 2 ) OPIC light detector
(PIN photodiode.and IC onto single device)
( 3 ) Can control the sensitivity by external resistance
( 4 ) Surface mount-leadless package
(Package dimensions: 5.0
脳
4.0
脳
1.295mm)
( 5 ) Applicable for reflow
OPIC Light Detector
*
OPIC Light Detector for 20脳 Speed Writing CD-R/RW power monitor
Outline Dimensions
4.0
3.5
0.4
(Unit:mm)
6
Detector
Center
5
4
0.8
3.6
5.0
2.0
0.895
P 1.25
1
2
3
Applications
Terminal configuration
1.295
( 1 ) CD-R/RW drives
( 2 ) CD-ROM drives
1
2
3
4
5
6
V
CC
V
REF
GND
R
OUT
R
IN
OUT
*
Specifications
"OPIC" (Optical IC) is a trademark of SHARP Corporation.
An OPIC consists of a light-detecting element and a signal-processing
circuit integrated onto a single chip.
(Ta=25藲C)
Parameter
Supply voltage
Output off-set voltage
DC output voltage ( Sensitivity )
Response frequency
Supply current
Response time
Maximum output amplitude
Temperature characteristic of Sensitivity
Operating temperature
Symbol
Vcc
Vod
Rp
fc
Icc
t
r
t
f
V
OL
TCRp
Topr
Characteristics
4.5 to 5.5 V
鹵
15 mV
TYP.
鈭?.0
mV/碌W
MIN. 40 MHz
TYP. 11 mA
TYP. 6 ns
TYP. 8 ns
MAX. 1.0V
TYP. 180 ppm/藲C
鈭?/div>
20 to + 70藲C
Condition
鈭?/div>
鈭?/div>
Po=100碌W,Ext. R = 470
鈩?/div>
f = 1 MHz base, -3dB
Under light shielding
鈭?/div>
鈭?/div>
鈭?/div>
Ext. R = 470
鈩?/div>
鈭?/div>
(Notice)
鈥n the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment
using any SHARP devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before
using any SHARP device.
鈥pecifications are subject to change without notice for improvement.
(Internet)
鈥ata for Sharp's optoelectronic/power devices is provided on internet. (Address http://sharp-world.com/ecg/)
1/2
D1-010605-B
