GA100TX03MZ
*OPIC
Light Detector for 16脳 Speed DVD-ROM
Features
( 1 ) OPIC light detector with built-in RF amplifier
(Integrates 12-division PIN photodiode and Amp.
IC onto a single chip)
( 2 ) For 12脳 to 16脳 Speed DVD-ROM
(Response frequency : MIN. 90 MHz)
( 3 ) Built-in capacitor for power supply bypass
( 4 ) Can read various discs such as DVD, DVD-ROM,
DVD-RAM, DVD-R, CD-ROM, CD-R, CD-RW
( 5 ) Differential Amp. output that can reduce external
disturbing noise
( 6 ) Surface mount-leadless package
(Package dimensions : 5.0
脳
5.55
脳
1.295mm)
( 7 ) Applicable for reflow
OPIC Light Detector
Outline Dimensions
5.55
14
13 12 11 10
(Unit:mm)
(1.295)
9 8
蠁
1
.6
Detector
Center
0.895
1 2
3 4
5
6 7
Terminal connection
1
2
3
4
5
6
7
Applications
( 1 ) DVD-ROM drives
( 2 ) DVD players
V
T4
V
A
V
RF+
V
RF-
V
B
V
T2
NC
8
GND
9
V
T1
10
11
12
13
14
V
C
V
s
V
CC
V
D
V
T3
* "OPIC" (Optical IC) is a trademark of SHARP Corporation.
An OPIC consists of a light-detecting element and a signal-processing
circuit integrated onto a single chip.
Specifications
(Ta=25藲C)
Parameter
Supply voltage
Output off-set voltage
Sensitivity (A,B,C,D)
Sensitivity (RF)
Response frequency
Output noise level
Operating temperature
Symbol
Vcc
Vod
Rp1
Rp2
fc (RF)
Vn (RF)
Topr
Characteristics
Input wavelength 650 nm
Input wavelength 780 nm
5.0
Condition
-
VA ~ VD
-
-
- 3 dB
f=72MHz,BW=30 kHz
-
D1-010603-B
4.75 to 5.25 V
鹵
25 mV
TYP. 24.6 mV/碌W
TYP. 22.9 mV/碌W
TYP. 15.2 mV/碌W
TYP. 14.1 mV/碌W
MIN. 70 MHz
MIN. 90 MHz
TYP. - 76 dBm
- 10 to + 80藲C
(Notice)
鈥n the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment
using any SHARP devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before
using any SHARP device.
鈥pecifications are subject to change without notice for improvement.
(Internet)
鈥ata for Sharp's optoelectronic/power devices is provided on internet. (Address http://sharp-world.com/ecg/)
