Under development
New product
GA100T8R7MZ
Features
( 1 ) OPIC light detector with built-in RF amplifier
(Integrates 8-division PIN photodiode and
Amp. IC onto a single chip)
CD-R
: 60脳 speed writing
CD-ROM : 60脳 speed reading
DVD-ROM: 12脳 speed reading
( 3 ) Built-in bypass capacitor for power supply
( 4 ) Can read various discs such as CD-ROM,
CD-R/RW, DVD-ROM, DVD-RAM/R/RW,
DVD+R/RW
( 5 ) Surface mount-leadless package
(Package dimensions: 5.0
脳
5.55
脳
1.295mm)
( 6 ) Applicable for reflow
OPIC Light Detector
*
OPIC Light Detector for 60脳 Speed Writing CD-R/RW, 12脳 Speed Reading DVD-ROM
Outline Dimensions
5.55
14
13 12 11 10
(Unit:mm)
1.295
9 8
桅
1
.6
Detector
Center
0.895
1 2
3 4
5
6 7
Terminal connection
1
2
3
4
5
6
7
5.0
V
CC
8
V
WRF
GND
9
V
C
10
V
B
V
E
V
G
11
V
H
12
V
F
V
A
13
GND
V
D
V
RRF
14
V
S
(位=780nm, Ta=25藲C)
Condition
Applications
( 1 ) CD-R/RW drives
( 2 ) DVD-R/RW drives
( 3 ) DVD+R/RW drives
*
"OPIC" (Optical IC) is a trademark of SHARP Corporation.
An OPIC consists of a light-detecting element and a signal-processing
circuit integrated onto a single chip.
Specifications
Parameter
Supply voltage
Output off-set voltage
Sensitivity 1
Sensitivity 2
Response frequency
Output noise level
Settling time
Operating temperature
Symbol
Vcc
Vod
RP1
RP2
fc
Vn
Tset
Topr
Characteristics
4.5 to 5.5 V
鹵
20 mV
TYP. 6.2 mV/碌W
TYP. 12.8 mV/碌W
MIN. 60 MHz
TYP. - 86 dBm
MAX. 11 ns
- 10 to + 70藲C
-
VA ~ VD
VA ~ VD
VRRF
VA ~ VD, 1 MHz base, -3 dB
VA ~ VD, f=36 MHz,BW=30 kHz
VA ~ VD, Output 1.25 V to 25 mV
-
(Notice)
鈥n the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment
using any SHARP devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before
using any SHARP device.
鈥pecifications are subject to change without notice for improvement.
(Internet)
鈥ata for Sharp's optoelectronic/power devices is provided on internet. (Address http://sharp-world.com/ecg/)
1/2
D1-020908
