GA100T8R42MZ
Features
( 1 ) Wide dynamic range : Vamp=1.8V(MIN.)
( 2 ) OPIC light detector with built-in RF amplifier
(Integrates 8-division PIN photodiode and
Amp. IC onto a single chip)
CD-R
: 40脳 speed writing
CD-ROM : 50脳 speed reading
DVD-ROM: 10脳 speed reading
( 3 ) Built-in bypass capacitor for power supply
( 4 ) Can read various discs such as CD-ROM,
CD-R/RW, DVD-ROM, DVD-RAM/R/RW,
DVD+R/RW
( 5 ) Surface mount-leadless package
(Package dimensions: 5.0
脳
5.55
脳
1.295mm)
( 6 ) Applicable for reflow
OPIC Light Detector
*
OPIC Light Detector for 40脳 Speed Writing CD-R/RW, 10脳 Speed Reading DVD-ROM
Outline Dimensions
5.55
14
13 12 11 10
(Unit:mm)
1.295
9 8
桅
1
.6
Detector
Center
0.895
1 2
3 4
5
6 7
5.0
Terminal connection
1
2
3
4
5
6
7
Applications
( 1 ) CD-R/RW drives
( 2 ) DVD-R/RW drives
( 3 ) DVD+R/RW drives
V
F2
V
A
V
RF
NC
V
B
V
E2
NC
8
GND
9
V
E1
10
11
12
13
14
V
C
V
s
V
CC
V
D
V
F1
*
"OPIC" (Optical IC) is a trademark of SHARP Corporation.
An OPIC consists of a light-detecting element and a signal-processing
circuit integrated onto a single chip.
Specifications
(位=780nm, Ta=25藲C)
Parameter
Supply voltage
Output off-set voltage
Sensitivity1
Sensitivity2
Response frequency
Dynamic range
Output noise level
Settling time
Operating temperature
Symbol
Vcc
Vod
RP1
RP2
fc
Vamp
Vn
Tset
Topr
Characteristics
4.5 to 5.5 V
鹵
20 mV
TYP. 8.0 mV/碌W
TYP. 20.0 mV/碌W
MIN. 50 MHz
MIN. 1.8 V
TYP. - 73 dBm
MAX. 24 ns
- 10 to + 80藲C
Condition
-
VA ~ VD, Vs base
VA ~ VD
VRF
VRF, -3 dB
VA ~ VD, V
S
base
VRF, f=36 MHz,BW=30 kHz
VA ~ VD, Output 1.8 V to 18 mV
-
(Notice)
鈥n the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment
using any SHARP devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before
using any SHARP device.
鈥pecifications are subject to change without notice for improvement.
(Internet)
鈥ata for Sharp's optoelectronic/power devices is provided on internet. (Address http://sharp-world.com/ecg/)
1/2
D1-020905
