GA100T802MZ1
GA100TX02MZA
*OPIC
Light Detector for 16x Speed DVD-ROM
Features
( 1 ) OPIC light detector with built-in RF amplifier
(Integrates PIN photodiode and Amp. IC onto
a single chip)
GA100TX02MZA
: 12-division PD
GA100T802MZ1
: 8-division PD
( 2 ) High speed response
(Response frequency : MIN. 90 MHz)
0.895
( 3 ) Built-in capacitor for power supply bypass
( 4 ) Can read various discs such as DVD,
DVD-ROM, DVD-RAM, DVD-R,
CD-ROM, CD-R, CD-RW
( 5 ) High sensitivity
( 6 ) Surface mount-leadless package
(Package dimensions : 5.0
脳
5.55
脳
1.295mm)
( 7 ) Applicable for reflow
OPIC Light Detector
Outline Dimensions
5.55
14
13 12 11 10
(Unit:mm)
(1.295)
9 8
Detector
Center
1 2
3 4
5
6 7
Terminal connection
GA100TX02MZA
1
2
3
4
5
6
7
GA100T802MZ1
1
2
3
4
5
6
7
Applications
( 1 ) DVD-ROM drives
( 2 ) DVD players
Specifications
Parameter
Supply voltage
Output off-set voltage
Sensitivity(A,B,C,D)
Sensitivity(RF)
Response frequency
Output noise level
Operating temperature
Symbol
Vcc
Vod
RP1
RP2
fc(RF)
Vn(RF)
Topr
V
EF1
8
GND
9
V
EF3
V
A
V
RF+
10
V
C
V
RF-
11
V
s
12
V
CC
V
B
V
EF2
13
V
D
NC
14
V
EF4
5.0
V
F2
8
GND
9
V
E1
V
A
V
RF+
10
V
C
V
RF-
11
V
s
12
V
CC
V
B
V
E2
13
V
D
NC
14
V
F1
(Ta=25藲C)
Condition
-
VA ~ VD, Vs base
VA ~ VD
VE1 ~ VF2
- 3 dB
f=72MHz,BW=30 kHz
-
D1-020902
蠁
1
.6
* "OPIC" (Optical IC) is a trademark of SHARP Corporation.
An OPIC consists of a light-detecting element and a signal-processing
circuit integrated onto a single chip.
Characteristics
Input wavelength 650 nm
Input wavelength 780 nm
4.75 to 5.25 V
鹵25
mV
TYP. 24.6 mV/碌W
TYP. 22.9 mV/碌W
TYP. 15.2 mV/碌W
TYP. 14.1 mV/碌W
MIN. 70 MHz
MIN. 90 MHz
TYP. - 76 dBm
- 10 to + 80藲C
(Notice)
鈥n the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment
using any SHARP devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before
using any SHARP device.
鈥pecifications are subject to change without notice for improvement.
(Internet)
鈥ata for Sharp's optoelectronic/power devices is provided on internet. (Address http://sharp-world.com/ecg/)
