Automotive High Current Relay
Automotive High Current Relay
Special purpose high power automotive relay.
(70 Amp)
Wide temperature range: 鈥?0
擄
C to +135
擄
C.
High current path fully welded 鈥?Reduces heat
build up at full load.
Insert moulded terminals 鈥?mechanical stability.
Standard ISO terminal foot print.
Made in North America.
G8JR
Available Types
Type
G8JR 1A7T R 12DC
G8JR 1A5T R 12DC
Contact form
SPST
SPST
Note
With Suppression Resistor
Mounting Bracket with Resistor
Contact Data
Resistive load (max.)
Inrush current (max.)
Contact Resistance
70A
150A
5m Ohm
Ratings/Specifications
Rated voltage
Operating voltage (max.)
Coil resistance
Pull in voltage
at +23
擄
C (max.)
at +125
擄
C (max.)
Drop-out voltage at +23
擄
C (min.)
Duty cycle at rated load (16 VDC at 125
擄
C)
Operate time (at 23
擄
C) (max.)
Release time (at 23
擄
C) (max.)
Operating ambient temperature
Mechanical life (min.)
Electrical life (resistive load) (min.)
Weight
12 VDC
16 VDC
65 Ohm
鹵
15%
9.0 VDC
11.0 VDC
1.0 VDC
100%
8.0 ms
4.0 ms
-40
擄
C to +135
擄
C
1,000,000 cycles
100,000 cycles
40g
