Power PCB Relay

s

Subminiature 20 L x 9.90 W x 9.90 H mm

s

s

s

s

G6B

(0.79 L x 0.39 W x 0.39 H in)

Low power consumption (200 mW)

Sealed construction permits automatic

soldering and cleaning of the PC board

High-capacity and latching types available

Meets FCC Part 68 requirements

Loop System) reduces relay size, magnetic

interference, and contact bounce time

s

Unique moving magnet armature (Moving

Ordering Information

To Order: Select the part number and add the desired coil voltage rating (e.g., G6B-1114-US-

DC6

).

s

NON-LATCHING

Type

Standard

Contact form

SPST-NO

SPST-NO + SPST-NC

DPST-NO

DPST-NC

High-capacity

LED indicator & diode surge suppression

SPST-NO

Sealed

Semi-sealed

Construction

Sealed

Part number

G6B-1114P-US

G6B-2114P-US

G6B-2214P-US

G6B-2014P-US

G6B-1174P-US

G6B-1177P-ND-US

s

LATCHING

Type

Single coil latching

Dual coil latching

Contact form

SPST-NO

Part number

G6BU-1114P-US

G6BK-1114P-US

s

ACCESSORIES

Back connecting sockets

Relay

G6B-1114P-US

G6B-1174P-US

G6B-1177P-US

G6BU-1114P-US

G6B-2114P-US

G6B-2214P-US

G6B-2014P-US

G6BK-1114P-US

P6B-06P

Part number

P6B-04P

P6B-26P
