Power PCB Relay

G5PA Relay Is Ideal for TV and Audio Equipment

Power Supplies

s

Meets TV-5 standards required for TV and

s

s

s

s

G5PA

audio equipment power supplies

High sensitivity coil with low 250 mW power

consumption

High impulse withstand surge of 10,000V

Double insulation construction assures high

insulation capability

UL, CSA, SEMKO, and TUV approved

Ordering Information

Type

Standard

Contact form

SPST-NO

Part number (semi-sealed)

G5PA-1-8

s

HOW TO ORDER

G5PA-1-8-DC__

add coil rating

Specifications

s

CONTACT DATA

Type

Load

Rated load

Contact material

Carry current

Max. operating voltage

Max. operating current

Max. switching capacity

Min. permissible load

Standard

Resistive (p.f. = 1)

5A at 250 VAC; 5A at 30 VDC

AgSnO

5A

250 VAC, 30 VDC

5A

1,250 VA, 150 W

100mA, 5 VDC

Capacitive (TV) Load

100 A inrush (0.3-0.35 ms)/3 A steady state at 125 VAC
