G3NA-425B Datasheet

  • G3NA-425B

  • 8頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Solid State Relay
A Wide Range of Models with 5- to 40-A
Output Currents and Up to
480-VAC/200-VDC Output Voltages
s
All models feature the same compact dimensions
s
s
s
s
s
G3NA
to provide a uniform mounting pitch
Built-in MOV effectively absorbs external surges
Operation indicator (red LED) enables monitoring
operation
Protective cover for greater safety
Standard models approved by UL/CSA
AC and DC input versions available
Ordering Information
To Order: Select the part number and add the desired rated input voltage, (e.g., G3NA-240B-
100 to 120 VAC
).
Isolation
Phototriac
Photocoupler
Zero cross
function
Yes
Indicator
Yes
Rated output load
(Applicable output load)
5 A at 24 to 240 VAC*
(19 to 264 VAC)
10 A at 24 to 240 VAC*
(19 to 264 VAC)
Photocoupler
Yes
鈥?/div>
Phototriac
Yes
Yes
10 A at 200 to 480 VAC*
(180 to 528 VAC)
10 A at 5 to 200 VDC*
(4 to 220 VDC)
20 A at 24 to 240 VAC*
(19 to 264 VAC)
Photocoupler
Photocoupler
Yes
Yes
Yes
Yes
20 A at 200 to 480 VAC*
(180 to 528 VAC)
25 A at 24 to 240 VAC*
(19 to 264 VAC)
25 A at 200 to 480 VAC*
Phototriac
Yes
Yes
(180 to 528 VAC)
40 A at 24 to 240 VAC*
(19 to 264 VAC)
40 A at 200 to 480 VAC*
(180 to 528 VAC)
Rated input voltage
5 to 24 VDC
100 to 120 VAC
200 to 240 VAC
5 to 24 VDC
100 to 120 VAC
200 to 240 VAC
5 to 24 VDC
100 to 240 VAC
5 to 24 VDC
100 to 240 VAC
5 to 24 VDC
100 to 120 VAC
200 to 240 VAC
5 to 24 VDC
100 to 240 VAC
5 to 24 VDC
100 to 120 VAC
200 to 240 VAC
5 to 24 VDC
100 to 240 VAC
5 to 24 VDC
100 to 120 VAC
200 to 240 VAC
Photocoupler
Yes
Yes
5 to 24 VDC
100 to 240 VAC
G3NA-440B
G3NA-420B
G3NA-225B
Part number
G3NA-205B
G3NA-210B
G3NA-410B
G3NA-D210B
G3NA-220B
G3NA-425B
G3NA-240B
* Loss time increases under 75 VAC.
NOTE:
When ordering a T脺V-approved model, add 鈥?UTU鈥?to the model number as shown below:
Example: G3NA-210B-
UTU
