Dupline
廬
Field- and Installationbus
Receiver for Digital Signals
Types G 3430 5511, G 3430 5521
鈥?8-channel receiver
鈥?Optoisolated NPN (sink) or PNP (source)
transistor outputs
鈥?Load: 8 x 0.7 A/60 VDC
鈥?Reverse-polarity protection
鈥?H4-housing
鈥?For mounting on DIN-rail (EN 50022)
鈥?LED-indications for supply and Dupline carrier
鈥?AC or DC power supply
鈥?Channel coding by GAP 1605
Product Description
Dupline receiver.
Open collector NPN or PNP
transistor outputs for control
of loads up to 60 VDC/0.7 A.
Ordering Key
Type: Dupline
H4-housing
Receiver
No. of channels
Output type
Power supply
G 3430 5521 024
Type Selection
Supply
Ordering no.
8 channels
0.7 A/60 VDC
NPN transistor
G 3430 5511 024
G 3430 5511 115
G 3430 5511 230
G 3430 5511 800
Ordering no.
8 channels
0.7 A/60 VDC
PNP transistor
G 3430 5521 024
G 3430 5521 115
G 3430 5521 230
G 3430 5521 800
24 VAC
115 VAC
230 VAC
10 to 30 VDC
Output Specifications
G 3430 5511 ...
(8 channels)
8 NPN transistors
1x8
6 to 60 VDC
Yes
鈮?/div>
0.7 A
51%
None
None
鈮?/div>
100 碌A(chǔ)
鈮?/div>
1.5 VDC
鈮?/div>
4 kVAC (rms)
G 3430 5521 ...
(8 channels)
8 PNP transistors
1x8
6 to 60 VDC
Yes
鈮?/div>
0.7 A
51%
None
None
鈮?/div>
100 碌A(chǔ)
鈮?/div>
1.5 VDC
鈮?/div>
4 kVAC (rms)
Outputs
Isolated in groups of
Output voltage range V
BB
Reverse-polarity protection
Current per output (25擄C)
Total load capability (25擄C)
Short-circuit protection
Built-in protective diodes
Off-state leakage current
Output voltage drop
Dielectric voltage
Outputs - Dupline
Specifications are subject to change without notice (06.09.99)
1
