Global Mixed-mode Technology Inc.

G1214

Rail-to-Rail I/O, High-Slew-Rate OP Amp

Features

+3V to +5.5V Single-Supply Operation

Input / Output Rail-to-Rail

Low input current

High output driving capacity

Low Quiescent Current: 500碌A(chǔ) @ 5V

High Slew rate 6.5V/碌s

High Gain-Bandwidth Product 6.5MHz

High Open Loop Gain 95dB

High PSRR 70dB

General Description

G1214 is a input/output rail-to-rail Operational Ampli-

fier. It can be operated from +3V to +5.5V single sup-

ply or from

鹵

1.5V to

鹵

2.75 dual supply. G1214 can

drive 66mA into resistor loads to within 10% power rail.

AC performance is very excellent with 6.5MHz band-

width, 6.5V/碌s Slew Rate, 95dB open loop gain, 60

degree phase margin and low distortion.

Supply current of G1214 is only 500碌A(chǔ) per Amplifier. It

is very suitable for low current consumption applica-

tions to control high current loads. Applications include

audio amplification for computers, sound ports, sound

cards and set-top boxes.

G1214 is housed in a 5-pins small SOT23-5 package.

Applications

Headphone Driver

Portable Equipment

Battery-Powered Equipment

Multimedia Audio

ASIC Input or Output Amplifier

Sensor Amplifier

Low Power/Low Voltage Applications

Ordering Information

PART MARKING TEMP. RANGE PIN-PACKAGE

G1214

14xx

0擄C to 85擄C

SOT 23-5

Pin Configuration

Typical Application Circuit

G1214

IN+

1

+

+

5

V

DD

IN

V

SS

2

1

3

VDD

5

+

G1214

G121

4

RL

2K

OUT

-

2

IN-

3

SOT23-5

4

OUT

Ver: 1.1

Jul 26, 2002

TEL: 886-3-5788833

http://www.gmt.com.tw

1
