Global Mixed-mode Technology Inc.
G1211
Rail-to-Rail I/O, 100mA Output Op Amp
Features
Single-Supply Operation: 4V to 6V
High Output Current: 鹵100mA
Low Supply Current: 500 碌A(chǔ)
Wide Bandwidth: 3 MHz
Slew Rate: 4 V/碌s
No Phase Reversal
Unity Gain Stable
Ultra-Small, 5-Pin SC70 Package
General Description
The G1211 is a rail-to-rail input and output sin-
gle-supply amplifiers featuring 100mA output drive
current. This high output current makes these amplifi-
ers excellent for driving either resistive or capacitive
loads. AC performance is very good with 3.0MHz
bandwidth; 4.0V/碌s slew rate and low distortion. All
are guaranteed to operate from a +4 to +6 volt single
supply.
The very low input bias currents enable the G1211 to
be used for integrators and diode amplification and
other applications requiring low input bias current. The
100mA high output current and supply current is only
850碌A(chǔ) per amplifier at 5 volts, allowing low current
applications to control high current loads.
Applications include audio amplification for computers,
sound ports, sound cards and set-top boxes. The
G1211 is very stable and capable of driving heavy
capacitive loads. The ability to swing rail-to-rail at the
inputs and outputs enables designers to buffer CMOS
ADC/DACs, ASICs or other wide output swing devices
in single-supply systems.
Applications
Battery-Powered Instruments
Portable Equipment
Audio Signal Conditioning
High-Side/Low-Side Current Sensors
Multimedia Audio
ASIC Input or Output Amplifier
Headphone Driver
Ordering Information
PART
G1211
TEMP. RANGE
0擄C to 70擄C
PIN-PACKAGE
SC70-5L
Pin Configuration
Tpypical Application Circuit
G1211
IN+
1
+
+
5
V
DD
IN
1
3
VDD
5
V
SS
2
+
G1211
4
OUT
-
2
RL
2K
IN-
3
SC70-5L
4
OUT
Ver 1.3
Oct 23, 2001
TEL: 886-3-5788833
http://www.gmt.com.tw
