8 x Digital Sensor Interface
FZE 1658G
Features
q
q
q
q
q
q
Input protection against 2000 V burst/500 V surge
pulse according to IEC 801 4/5
Input characteristic according to IEC 65 A, type 2
(24 V DC)
Digital filter
Serial in/out for easy cascading
Low power dissipation
SMD package
P-DSO-24-1
Type
FZE 1658G
Ordering Code
Q67000-A8361
Package
P-DSO-24-1
The FZE 1658G is an integrated interface for digital sensors - i.e. proximity switches - in
industrial automation equipment. The IC has eight integrated highly protected and
failsafe inputs with status LED and a serial synchronous output for direct MC-interfacing.
Semiconductor Group
1
01.97
