Data Sheet, Rev. 2
October 2002
鈩?/div>
FW323 06
1394A PCI PHY/Link Open Host Controller Interface
Features
s
1394a-2000 OHCI link and PHY core function in a
single device:
鈥?Single-chip link and PHY enable smaller, simpler,
more efficient motherboard and add-in card
designs
鈥?Enables lower system costs
鈥?Leverages proven 1394a-2000 PHY core design
鈥?Demonstrated compatibility with current
Microsoft
Windows
廬
drivers and common applications
鈥?Demonstrated interoperability with existing, as well
as older, 1394 consumer electronics and periph-
erals products
鈥?Feature-rich implementation for high performance
in common applications
鈥?Supports low-power system designs (CMOS
implementation, power management features)
鈥?Provides LPS, LKON, and CNA outputs to support
legacy power management implementations
OHCI:
鈥?Complies with the
1394 OHCI 1.1 Specification
鈥?OHCI 1.0 backwards compatible鈥攃onfigurable via
EEPROM to operate in either OHCI 1.0 or
OHCI 1.1 mode
鈥?Complies with
Microsoft Windows
logo program
system and device requirements
鈥?Listed on
Windows
hardware compatibility list
http://www.microsoft.com/hcl/results.asp
鈥?Compatible with
Microsoft Windows
and
MacOS
廬
operating systems
鈥?4 Kbyte isochronous transmit FIFO
鈥?2 Kbyte asynchronous transmit FIFO
鈥?4 Kbyte isochronous receive FIFO
鈥?2 Kbyte asynchronous receive FIFO
鈥?Dedicated asynchronous and isochronous
descriptor-based DMA engines
鈥?Eight isochronous transmit contexts
鈥?Eight isochronous receive contexts
鈥?Prefetches isochronous transmit data
鈥?Supports posted write transactions
鈥?Supports parallel processing of incoming physical
read and write requests
鈥?Supports notification (via interrupt) of a failed
register access
1394a-2000 PHY core:
鈥?Compliant with
IEEE
廬
1394a-2000,
Standard for a
High Performance Serial Bus
(Supplement)
鈥?Provides three fully compliant cable ports, each
supporting 400 Mbits/s, 200 Mbits/s, and
100 Mbits/s traffic
s
鈥?Supports extended BIAS_HANDSHAKE time for
enhanced interoperability with camcorders
鈥?While unpowered and connected to the bus, will
not drive TPBIAS on a connected port even if
receiving incoming bias voltage on that port
鈥?Does not require external filter capacitor for PLL
鈥?Supports link-on as a part of the internal
PHY core-link interface
鈥?25 MHz crystal oscillator and internal PLL provide
transmit/receive data at 100 Mbits/s, 200 Mbits/s,
and 400 Mbits/s, and internal link-layer controller
clock at 50 MHz
鈥?Interoperable across 1394 cable with 1394 phys-
ical layers (PHY core) using 5 V supplies
鈥?Provides node power-class information signaling
for system power management
鈥?Supports ack-accelerated arbitration and fly-by
concatenation
鈥?Supports arbitrated short bus reset to improve
utilization of the bus
鈥?Fully supports suspend/resume
鈥?Supports connection debounce
鈥?Supports multispeed packet concatenation
鈥?Supports PHY pinging and remote PHY access
packets
鈥?Reports cable power fail interrupt when voltage at
CPS pin falls below 7.5 V
鈥?Provides separate cable bias and driver termina-
tion voltage supply for each port
s
Link:
鈥?Cycle master and isochronous resource manager
capable
鈥?Supports 1394a-2000 acceleration features
PCI:
鈥?Revision 2.2 compliant
鈥?33 MHz/32-bit operation
鈥?Programmable burst size thresholds for PCI data
transfer
鈥?Supports optimized memory read line, memory
read multiple, and memory write invalidate burst
commands
鈥?Supports
PCI Bus Power Management Interface
Specification
v.1.1, including D3cold wakeups
鈥?Supports CLKRUN# protocol per PCI Mobile
Design Guide
鈥?Supports
Mini PCI Specification
v1.0, including
Mini PCI power requirements
鈥?Global byte swap function
鈥?CardBus support per PC Card Standard
Release 8.0, including 128 bytes of on-chip tuple
memory.
s
s
