FTZ5.6E
Diodes
Zener diode
FTZ5.6E
!
Applications
Constant voltage control
Noise suppression on signal line
!
External dimensions
(Units: mm)
2.9鹵0.2
1.9鹵0.2
0.95 0.95
1.1 +0.2
鈭?.1
0.8鹵0.1
0.3~0.6
!
Features
1) Small surface mounting type.(SMD5)
2) Multiple diodes with common anode configuration.
3) High reliability.
D6E
2.8鹵0.2
1.6 +0.2
鈭?.1
0~0.1
0.3 +0.1
鈭?.05
+0.1
0.15
鈭?.06
(All leads have the same dimensions.)
!
Construction
Silicon epitaxial planar
ROHM : SMD5
EIAJ : SC-74A
JEDEC :
鈭?/div>
!
Circuit
!
Absolute maximum ratings
(Ta = 25擄C)
Parameter
Power dissipation
鈭?/div>
Junction temperature
Storage temperature
鈭?/div>
Total of 4 elements
Symbol
P
Limits
200
125
-55~+125
Unit
mW
藲C
藲C
Tj
Tstg
!
Electrical characteristics
(Ta = 25擄C)
Parameter
Zener voltage
Reverse current
Operating resistance
Rising operating resistance
Symbol
V
Z
I
R
Z
z
Z
ZK
Min.
5.31
鈭?/div>
鈭?/div>
鈭?/div>
Typ.
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
Max.
5.92
1
60
200
Unit
V
碌A(chǔ)
鈩?/div>
鈩?/div>
I
Z
= 5mA
V
R
= 2.5V
I
Z
= 5mA
I
Z
= 0.5mA
Conditions
