FST7120SM
THRU
FST71100SM
70
Amp
Schottky Barrier
Rectifier
20
to 100 Volts
MINIMOD-SM
F
Metal of siliconrectifier, majonty carrier conducton
Guard ring for transient protection
Low power loss high efficiency
High surge capacity, High current capability
Maximum Ratings
鈥?/div>
鈥?/div>
Operating Temperature: -65擄C to +150擄C
Storage Temperature: -65擄C to +150擄C
Maximum
Recurrent
Peak Reverse
Voltage
20V
30V
35V
40V
45V
60V
80V
100V
Maximum DC
Blocking
Voltage
20V
30V
35V
40V
45V
60V
80V
100V
A
P
E
MCC
Part Number
FST7120SM
FST7130SM
FST7135SM
FST7140SM
FST7145SM
FST7160SM
FST7180SM
FST71100SM
Maximum
RMS Voltage
14V
21V
24.5V
28V
31.5V
42V
56V
70V
M
K
G
C
B
J
H
Electrical Characteristics @ 25擄C Unless Otherwise Specified
Average Forward
Current
Peak Forward Surge
Current
Maximum
Instantaneous
Forward Voltage
FST7120-7145SM
FST7160SM
FST7180-71100SM
Maximum DC
Reverse Current At
Rated DC Blocking
Voltage
Typical Junction
Capacitance
I
F(AV)
I
FSM
70
A
800A
T
A
=
100擄C
8.3ms, half sine
I
FM
=
30.0A;
T
A
= 25擄C
DIM
A
B
C
E
F
G
H
J
K
L
M
N
P
DIMENSIONS
INCH
ES
MIN
1.180
.220
.027
.350
1.490
.695
.088
.240
.115
.230
.065
.151
.015
MM
MIN
29.97
5.08
0.69
8.89
37.85
17.65
2.24
6.10
2.92
5.84
1.65
3.84
0.38
V
F
.50 V
.75 V
.84 V
I
R
5.0
mA
T
A
= 25擄C
MAX
1.195
NOM
.037
.370
1.510
.715
.098
.260
.135
.250
.085
.161
.025
MAX
30.35
NOM
0.94
9.40
38.35
18.16
2.49
6.60
3.43
6.35
2.16
4.09
0.64
NOTE
2PL
鈭?/div>
C
J
240pF
Measured at
1.0MHz, V
R
=4.0V
*Pulse Test: Pulse Width 300碌sec, Duty Cycle 1%
