FSBS10CH60 Smart Power Module
April 2005
FSBS10CH60
Smart Power Module
Features
鈥?UL Certified No.E209204(SPM27-BA package)
鈥?600V-10A 3-phase IGBT inverter bridge including control ICs
for gate driving and protection
鈥?Divided negative dc-link terminals for inverter current sensing
applications
鈥?Single-grounded power supply due to built-in HVIC
鈥?Isolation rating of 2500Vrms/min.
鈥?Very low leakage current due to using ceramic substrate
SPM
General Description
TM
Applications
鈥?AC 100V ~ 253V three-phase inverter drive for small power
ac motor drives
鈥?Home appliances applications like air conditioner and wash-
ing machine
It is an advanced smart power module (SPM
TM
) that Fairchild
has newly developed and designed to provide very compact
and high performance ac motor drives mainly targeting low-
power inverter-driven application like air conditioner and wash-
ing machine. It combines optimized circuit protection and drive
matched to low-loss IGBTs. System reliability is further
enhanced by the integrated under-voltage lock-out and short-
circuit protection. The high speed built-in HVIC provides opto-
coupler-less single-supply IGBT gate driving capability that fur-
ther reduce the overall size of the inverter system design. Each
phase current of inverter can be monitored separately due to
the divided negative dc terminals.
Top View
44mm
Bottom View
26.8mm
Figure 1.
漏2005 Fairchild Semiconductor Corporation
1
www.fairchildsemi.com
FSBS10CH60 Rev. C
