DIODE MODULE
F.R.D.
FRG25BA60
UL;E76102 M
FRG25BA60
is a high speed isolated diode module designed for high power switching
application.
FRG25BA60
is suitable for high frequency application requiring low loss
and high speed control.
High Speed t
rr
100ns
I
F AV
25A
Isolated Mounting base.
High Surge Capability
Applications
Inverter Welding Power Supply
Power Supply for Telecommunication
Various Switching Power Supply.
Unit
Maximum Ratings
Symbol
V
RRM
V
R
DC
Tj 25
Ratings
FRG25BA60
600
480
Conditions
D.C. T
C
94
1
Item
Repetitive Peak Reverse Voltage
D.C. Reverse Voltage
Item
Forward Current
Surge Forward Current
I
2
t
Operating Junction Temperature
Storage Temperature
Isolation Breakdown Voltage R.M.S.
Mounting Torque
Mass
Mounting M4
A.C. 1 minute
Unit
V
V
Ratings
25
450
840
40
150
V
Nm
f
B
g
40
125
2500
1.5 15
23
Unit
A
A
A
2
S
Symbol
I
F
I
FSM
It
2
cycle, 60H
Z
, peak value, non-repetitive
Value for One cycle of surge curent
2
Tj
Tstg
V
ISO
Recommended Value 1.0 1.4 10 14
Typical Value
Electrical Characteristics
Symbol
I
RRM
V
FM
trr
Rth j-c
Item
Repetitive Peak Reverse Current
Forward Voltage Drop
Reverse Recovery Time
Thermal Impedance
Tj 150
Tj 25
Conditions
at V
RRM
600V
I
F
25A, Inst. measurement
Ratings
Min.
Typ. Max.
25
1.20
80
30
1.30
100
1.6
Unit
mA
V
ns
/W
I
F
25A di/dt 100A/ s
Junction to case
1
1
2
