Glass Passivated Fast Recovery Rectifier
FR8A01F-G THRU FR8A07F-G
Voltage Range 50 to 1000 V
Current 8.0 Ampere
Features
Fast switching for high efficiency
Low forward voltage drop
High current capability
Low reverse leakage current
High surge current capability
Mechanical Data
Case: Molded plastic ITO-220AC
Epoxy: UL 94V-0 rate flame retardant
Terminals: Solderable per MIL-STD-202
method 208
Polarity:Color band denotes cathode
Mounting position: Any
Weight: 1.16 grams
ITO-220AC
.113(2.87)
.103(2.62)
.185(4.70)
.175(4.44)
MAX.412(10.5)
DIA .140(3.56)
.130(3.30)
1.25(3.18)
1.15(2.92)
PIN
1
MAX.0.05(1.5)
2
.16(4.06)
.14(3.56)
.56(14.22)
.53(13.46)
.27(6.86)
.23(5.84)
.594(15.1)
.587(14.9)
.037(0.94)
.027(0.68)
1
2
.11(2.79)
.10(2.54)
.205(5.20)
.195(4.95)
.025(0.64)
.014(0.35)
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating at 25
o
C
ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
SYMBOL
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified
Current T
C
=100
C
Peak Forward Surge Current, 8.3ms single
Half sine-wave superimposed on rated load
(JEDEC method)
Maximum Instantaneous Forward Voltage
@ 8.0 A
Maximum DC Reverse Current @T
J
=25
C
At Rated DC Blocking Voltage @T
J
=125
C
Maximum Reverse Recovery Time (Note 1)
Typical junction Capacitance (Note 2)
Typical Thermal Resistance (Note 3)
Operating Junction and Storage
Temperature Range
o
o
o
V
RRM
V
RMS
V
DC
IF
(AV)
FR
8A01F
-G
50
35
50
FR
8A02F
-G
100
70
100
FR
8A03F
-G
200
140
200
FR
8A04F
-G
400
280
400
8.0
FR
8A05F
-G
600
420
600
FR
8A06F
-G
800
560
800
FR
UNIT
8A07F
-G
V
1000
700
1000
V
V
A
I
FSM
150
A
V
F
1.3
10.0
250
150
65
2.2
-55 to + 150
o
V
uA
uA
250
500
nS
pF
CW
o
I
R
Trr
C
J
R
JC
T
J
, T
STG
C
NOTES : (1) Reverse recovery test conditions I
F
= 0.5A, I
R
= 1.0A, Irr = 0.25A.
(2) Measured at 1.0 MHz and applied reverse voltage of 4.0 Volts DC.
(3) Thermal Resistance junction to case.
COMCHIP TECHNOLOGY 4115 CLIPPER CT. FREMONT CA 94538 TEL: (510) 657-8671 FAX: (510) 657-8921
