Data Sheet
3.0 Amp FAST RECOVERY
PLASTIC RECTIFIERS
Mechanical Dimensions
JEDEC
D0-201AD
.190
.210
.285
.375
1.00 Min.
Description
FR30 . . . 310 Series
.050 typ.
Features
n
FAST SWITCHING FOR
HIGH EFFICIENCY
n
HIGH SURGE CAPABILITY
n
3.0 AMP OPERATION @ T
A
= 105擄C, WITH
NO THERMAL RUNAWAY
n
MEETS UL SPECIFICATION 94V-0
FR30. . . 310 Series
Maximum Ratings
Peak Repetitive Reverse Voltage...V
RRM
RMS Reverse Voltage...V
R(rms)
DC Blocking Voltage...V
DC
Average Forward Rectified Current...I
F(av)
T
A
= 55擄C
Non-Repetitive Peak Forward Surge Current...I
FSM
@ Rated Current & Temp
Operating & Storage Temperature Range...T
J
, T
STRG
Electrical Characteristics
Maximum Forward Voltage @ 3.0A...V
F
Maximum DC Reverse Current...I
R
@ Rated DC Blocking Voltage
@
@
25擄C
100擄C
............................................. 1.3 ...............................................
FR30
50
35
50
FR31
100
70
100
FR32
200
140
200
FR34
400
280
400
FR36
600
420
600
FR38
800
560
800
FR310
1000
700
1000
Units
Volts
Volts
Volts
Amps
............................................. 3.0 ...............................................
............................................. 200 ...............................................
Amps
........................................ -65 to 150 .........................................
擄C
Volts
............................................. 5 0 ...............................................
碌A(chǔ)mps
............................................. 100 ...............................................
碌A(chǔ)mps
............................................. 6 0 ...............................................
150
150
150
150
250
500
500
pF
ns
Typical Junction Capacitance...C
J
(Note 1)
Maximum Reverse Recovery Time...t
RR
