FEATURES
. Fast switching
. Low leakage
. Low forward voltage drop
. High current capability
. High current surge
. High reliability
FR151 THRU FR157
FAST RECOVERY RECTIFIER
Reverse Voltage - 50 to 1000 Volts
Forward Current - 1.5Amperes
MECHANICAL DATA
.
Case:
JEDEC DO-15 molded plastic body
.
Terminals:
Plated axial leads,solderable per MIL-STD-750,method 2026
.
Polarity:
Color band denotes cathode end
.
Mounting Position:
Any
.
Weight:
0.014 ounce, 0.39 gram
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(Ratings at 25
ambient temperature unless otherwise specified,Single phase,half wave 60Hz,resistive or inductive)
load. For capacitive load,derate current by 20%)
Symbols FR151 FR152 FR153 FR154 FR155 FR156 FR157
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Macimum average forward rectified
current 0.375"(9.5mm)lead length at
T
A
=75
Peak forward surge current 8.3ms
sing-wave superimposed on rated load
(JEDEC method)
Maximum instantaneous forward voltage at 1.5 A
Maximum DC Rreverse Current at rated DC
blocking voltage
Maximum full load reverse current full cycle
average. 0.375"(9.5mm)lead length at
I
R
40.0
V
F
1.3
5.0
I
FSM
60.0
V
RRM
V
RMS
V
DC
I
(AV)
50
35
50
100
70
100
200
140
200
400
280
400
1.5
600
420
600
800
560
800
1000
700
100
Units
Volts
Volts
Volts
Amp
Amps
Volts
A
T
L
=55
Maximum reverse recovery time(Note 1)
Typical junction Capacitance(Note 2)
Operating and storage temperature range
Trr
150
15.0
-65 to +150
250
500
ns
pF
C
J
T
J
T
STG
Notes:
1.Test conditions:I
F
=0.5A,I
R
=1.0A,Irr=0.25A.
2.Measured at 1MHz and applied reverse voltage of 4.0V Volts
