Differential Magnetoresistive Sensor

FP 210 L 100-22

Features

鈥?High operating

temperature

鈥?High output voltage

鈥?Robust cylindrical

housing

鈥?Biasing magnet build in

鈥?Signal amplitude

independent of speed

鈥?Easily connectable

Typical applications

鈥?Detection of speed

鈥?Detection of position

鈥?Detection of sense of

rotation

鈥?Angle encoder

鈥?Linear position sensing

Dimensions in mm

Type

FP 210 L 100-22

Ordering Code

Q65210-L100-W4

The differential magnetoresistive sensor FP 210 L 100-22 consists of two series coupled

L-type InSb/NiSb semiconductor resistors. The resistance value of the MRs, which are

mounted onto an insulated ferrite substrate, can be magnetically controlled. The sensor

is encapsulated in a plastic package with three in-line contacts extending from the base.

The basic resistance of the total system in the unbiased state is 2脳100

鈩?

A permanent

magnet which supplies a biasing magnetic field is built into the housing.

Semiconductor Group

1

07.96
