12,500 V - 20,000 V Rectifier Stacks

2.2 A Forward Current

3000 ns Recovery Time

FP125S FP150S

FP175S FP200S

ELECTRICAL CHARACTERISTICS AND MAXIMUM RATINGS

Part Number

Working

Reverse

Voltage

(Vrwm)

Average

Rectified

Current

(in oil)

(Io)

55擄C

Volts

FP125S

FP150S

FP175S

FP200S

Amps

100擄C

Amps

Reverse

Current

@ Vrwm

(Ir)

25擄C

碌A(chǔ)

100擄C

碌A(chǔ)

25擄C

Volts

Amps

Forward Voltage

1 Cycle

Surge

Current

tp=8.3ms

(Ifsm)

25擄C

Amps

Repetitive

Surge

Current

(Ifrm)

25擄C

Amps

Reverse

Recovery

Time

(1)

(Trr)

25擄C

ns

in.

Case Length

(L)

(Vf)

12500

15000

17500

20000

2.2

2.2

2.2

2.2

1.3

1.3

1.3

1.3

2.0

2.0

2.0

2.0

50

50

50

50

27.5

33.0

38.5

44.0

4.0

4.0

4.0

4.0

120

120

120

120

20

20

20

20

3000

3000

3000

3000

5.500

6.500

6.500

6.500

8

(1)Trr Testing: If=0.5A, Ir=1.0A, Irr=0.25A *Op. Temp.= -55擄C to +150擄C Stg. Temp.= -55擄C to +150擄C

2.00(50.80)

MIN.

.690 鹵.020

(17.53 鹵.50)

L 鹵.020

.051 鹵.003

(1.30 鹵.08)

.380 鹵.020

(9.65 鹵.50)

Dimensions: In. (mm) 鈥?All temperatures are ambient unless otherwise noted. 鈥?Data subject to change without notice.

VOLTAGE MULTIPLIERS INC.

8711 W. Roosevelt Ave.

Visalia, CA 93291

TEL

559-651-1402

FAX

559-651-0740

www.voltagemultipliers.com

197
