FMS3818/3820
Triple Video D/A Converters
3 x 8 bit, 200 Ms/s
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鹵 2.5% gain matching
鹵 1 LSB linearity error
Internal bandgap voltage reference
Low glitch energy
Single 3.3 Volt power supply
Description
FMS3818/3820 products are low-cost triple D/A converters,
tailored to 鏗乼 graphics and video applications where speed is
critical. Two speed grades are available:
FMS3818
FMS3820
180 Ms/s
200 Ms/s
Preliminary Information
Applications
鈥?PC Graphics
鈥?Video signal conversion
鈥?RGB
鈥?YC
B
C
R
鈥?Composite, Y, C
CMOS-level inputs are converted to analog current outputs
that can drive 25鈥?7.5
鈩?/div>
loads corresponding to doubly-termi-
nated 50鈥?5
鈩?/div>
loads. A sync current following SYNC input
timing is added to the I
OG
output. BLANK will override
RGB inputs, setting I
OG
, I
OB
and I
OR
currents to zero when
BLANK = L. Although appropriate for many applications
the internal 1.25V reference voltage can be overridden by the
V
REF
input.
Few external components are required, just the current
reference resistor, current output load resistors, bypass
capacitors and decoupling capacitors.
Package is a 48-lead LQFP. Fabrication technology is
CMOS. Performance is guaranteed from 0 to 70擄C.
Block Diagram
SYNC
BLANK
SYNC
I
OS
G
7-0
8
8 bit D/A
Converter
IO
G
B
7-0
8
8 bit D/A
Converter
IO
B
R
7-0
CLK
8
8 bit D/A
Converter
IO
R
COMP
R
REF
V
REF
+1.25V
Ref
REV. 1.1.7 9/25/01
