Impedance Matched Zin/Zout = 50鈩?/div>
Hermetically Sealed Package (12 X 15 X 3.5mm)
DESCRIPTION
The FMM5522GJ is a module that contains a two-stage amplifier,
internally matched, for standard communications in the 14.0 to 14.5GHz
frequency range. This product is well suited for VSAT applications as it
offers high power, high gain, and low VSWR.
Fujitsu鈥檚 stringent Quality Assurance Program assures the highest
reliability and consistent performance.
ABSOLUTE MAXIMUM RATINGS (Ambient Temperature Ta = 25擄C)
Parameter
DC Input Voltage
DC Input Voltage
Input Power
Storage Temperature
Operating Case Temperature
Symbol
VDD
VGG
Pin
Tstg
Top
Rating
12
-7
12
-55 to +125
-55 to +85
Unit
V
V
dBm
擄C
擄C
Fujitsu recommends the following conditions for the reliable operation of GaAs modules:
1. The drain operating voltage (VDD) should not exceed 10 volts.
2. The gate operating voltage (VGG) should not exceed -5 volts.
ELECTRICAL CHARACTERISTICS (Case Temperature Tc = 25擄C)
Item
Frequency Range
Output Power at 1dB G.C.P.
Power Gain at 1dB G.C.P.
Gain Flatness
Input VSWR
Output VSWR
DC Input Current
DC Input Current
Symbol
f
P1dB
G1dB
鈭咷
VSWRi
VSWRo
IDD
IGG
VDD = 10V
VGG = -5V
VDD = 10V
VGG = -5V
f = 14.0 ~ 14.5GHz
Condition
Min.
Limit
Typ. Max.
35.0
26.0
-
2:1
3:1
1.75
22
-
-
鹵1.0
2.5:1
3.5:1
2.0
25
Unit
GHz
dBm
dB
dB
-
-
A
mA
14.0 - 14.5
33.5
23.0
-
-
-
-
-
CASE STYLE:
GJ
G.C.P.: Gain Compression Point
Edition 1.5
October 1999
