FLM5964-45F
C-Band Internally Matched FET
FEATURES
銉籋igh
Output Power: P1dB=47.0dBm(Typ.)
銉籋igh
Gain: G1dB=8.5dB(Typ.)
銉籋igh
PAE:
畏add=39%(Typ.)
銉籅road
Band: 5.9~6.4GHz
銉籌mpedance
Matched Zin/Zout = 50鈩?/div>
銉籋ermetically
Sealed Package
DESCRIPTION
The FLM5964-45F is a power GaAs FET that is internally matched
for standard communication bands to provide optimum power and
gain in a 50鈩?system.
ABSOLUTE MAXIMUM RATINGS (Case Temperature Tc=25
o
C)
Item
Drain-Source Voltage
Gate-Source Voltage
Total Pow er Dissipation
Storage Tem perature
Channel Tem perature
Symbol
V
DS
V
GS
P
T
T
s t g
T
ch
Rating
15
-5
115
-65 to +175
175
Unit
V
V
W
o
C
o
C
RECOMMENDED OPERATING CONDITION(Case Temperature Tc=25
o
C)
Item
DC Input Voltage
Forw ard Gate Current
Reverse Gate Current
Sym bol
V
DS
I
GF
I
GR
Condition
RG=10
鈩?/div>
RG=10
鈩?/div>
Lim it
鈮?/div>
10
鈮?/div>
108
鈮?/div>
-23.2
Unit
V
mA
mA
ELECTRICAL CHARACTERISTICS (Case Temperature Tc=25
o
C)
Item
Drain Current
Transconductance
Pinch-off Voltage
Gate-Source Breakdow n Voltage
Output Pow er at 1dB G.C.P.
Pow er Gain at 1dB G.C.P.
Drain Current
Pow er-added Efficiency
Gain Flatness
3rd Order Interm odulation
Distortion
Therm al Resistance
Channel Tem perature Rise
CASE STYLE : IK
ESD
Sym bol
I
DSS
g
m
V
p
V
GSO
P
1d B
G
1d B
I
d s r
畏
ad d
鈭?/div>
G
IM
3
R
th
鈭?/div>
T
ch
Class III
Condition
VDS=5V, VGS=0V
VDS=5V, IDS=8.0A
VDS=5V, IDS=480mA
IGS=-480uA
VDS=10V
f=5.9 - 6.4 GHz
IDS(DC)=8.0A(typ.)
Zs=ZL=50
鈩?/div>
f=6.4 GHz
鈭?/div>
f=10MHz, 2-tone Test
Pout=35.5dBm(S.C.L.)
Channel to Case
10V x IDS(DC) X R
th
2000V
銆€
~
Lim it
Min.
-
-
-0.5
-5.0
46.0
7.5
-
-
-
-37
-
-
Typ.
24
16
-1.5
-
47.0
8.5
11
39
-
-40
1.1
-
Max.
-
-
-3.0
-
-
-
13
-
1.2
-
1.3
100
Unit
A
S
V
V
dBm
dB
A
%
dB
dBc
o
C/W
o
C
G.C.P.:Gain Compression Point
Note : Based on EIAJ ED-4701 C-111A(C=100pF, R=1.5k
鈩?/div>
)
Edition 1.3
September 2004
1
