FDP20N40 Datasheet

  • FDP20N40

  • 20A, 400V, 0.216 Ohm, N-Channel SMPS Power MOSFET

  • 6頁

  • FAIRCHILD

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

FDH20N40 / FDP20N40
October 2002
FDH20N40 / FDP20N40
20A, 400V, 0.216 Ohm, N-Channel SMPS Power MOSFET
Applications
Switch Mode Power Supplies(SMPS), such as
鈥?PFC Boost
鈥?Two-Switch Forward Converter
鈥?Single Switch Forward Converter
鈥?Flyback Converter
鈥?Buck Converter
鈥?High Speed Switching
Features
鈥?Low Gate Charge
Requirement
Q
g
results
in
Simple
Drive
鈥?Improved Gate, Avalanche and High Reapplied dv/dt
Ruggedness
鈥?Reduced r
DS(ON)
鈥?Reduced Miller Capacitance and Low Input Capacitance
鈥?Improved Switching Speed with Low EMI
鈥?175擄C Rated Junction Temperature
Package
JEDEC TO-247
SOURCE
DRAIN
GATE
Symbol
JEDEC TO-220AB
D
SOURCE
DRAIN
GATE
G
DRAIN
(FLANGE)
DRAIN
(FLANGE)
S
Absolute Maximum Ratings
T
C
= 25擄C unless otherwise noted
Symbol
V
DSS
V
GS
Parameter
Drain to Source Voltage
Gate to Source Voltage
Drain Current
I
D
Continuous (T
C
= 25
o
C, V
GS
= 10V)
Continuous (T
C
= 100
o
C, V
GS
= 10V)
Pulsed (Note 1)
P
D
T
J
, T
STG
Power dissipation
Derate above 25
o
C
Operating and Storage Temperature
Soldering Temperature for 10 seconds
Mounting Torque, 8-32 or M3 Screw
20
14
80
273
1.82
-55 to 175
300 (1.6mm from case)
10ibf*in (1.1N*m)
A
A
A
W
W/
o
C
o
o
Ratings
400
鹵30
Units
V
V
C
C
Thermal Characteristics
R
胃JC
R
胃CS
R
胃JA
R
胃JA
Thermal Resistance Junction to Case
Thermal Resistance Case to Sink, Flat, Greased Surface
Thermal Resistance Junction to Ambient (TO-247)
Thermal Resistance Junction to Ambient (TO-220)
0.55
0.24
40
62
o
C/W
C/W
C/W
o
C/W
o
o
漏2002 Fairchild Semiconductor Corporation
FDH20N40 / FDP20N40 Rev. A,

FDP20N40 產品屬性

  • Fairchild Semiconductor

  • MOSFET

  • N-Channel

  • 400 V

  • +/- 30 V

  • 20 A

  • 0.216 Ohms

  • Single

  • + 175 C

  • Through Hole

  • TO-220

  • Tube

  • 34 ns

  • - 55 C

  • 273 W

  • 32.5 ns

  • 400

  • 30 ns
