Future
Communications
Integrated
circuit Inc.
FC7103
Power Amplifier Module for CDMA/AMPS
D
ESCRIPTION
The FC7103 is a high power, high efficiency
amplifier module for dual mode AMPS/CDMA
wireless handset applications. The device is
manufactured on an advanced InGaP HBT
MMIC technology. Selectable bias modes that
optimize efficiency for different output power
levels, and a shutdown mode with low leakage
current, serve to increase handset talk and
standby time. The 10 Pin 4mm X 4mm surface
mount package offers premium performance in
a 50
鈩?/div>
system.
F
EATURES
l
Operating Frequency: 824~849MHz
l
High Efficiency
n
56% AMPS, 42.5% CDMA
l
Very Low Quiescent Current: 32mA
l
Low Leakage Current in Shutdown
Mode: < 3uA
l
Optimized for a 50
鈩?/div>
System
P
IN
C
ONFIGURATION
A
PPLICATIONS
l
Single Mode CDMA Wireless Handsets
l
Dual Mode AMPS/CDMA Wireless Handsets
F
UNCTIONAL
B
LOCK
D
IAGRAM
(X- ray Transparency Top View)
For latest specifications, technical questions and additional product information, visit our website or e-mail us.
Web: http://www.fci.co.kr
FCI Inc.
E-mail : info@fci.co.kr
2nd Fl. Korea First Bank B/D, 6-8 Sunae-Dong Pundang-Gu,
Sungnam City, Kyunggi-do,
Tel : 82-31-711-6444
463-020, KOREA
Fax: 82-31- 714-6576
Preliminary
1/6
Last Update 02/25/04
