FBR600 - FBR610
PRV : 50 - 1000 Volts
Io : 6.0 Amperes
FEATURES :
*
*
*
*
*
*
*
High case dielectric strength
High surge current capability
High reliability
Low reverse current
Low forward voltage drop
Fast switching for high efficiency
Ideal for printed circuit board
FAST RECOVERY
BRIDGE RECTIFIERS
BR6
0.445 (11.30)
0.405 (10.30)
蠁
0.158 (4.00)
0.142 (3.60)
+
AC
0.62 (15.75)
0.58 (14.73)
0.127 (3.20)
0.047 (1.20)
0.042 (1.06)
0.038 (0.96)
0.75 (19.1)
Min.
0.27 (6.90)
0.23 (5.80)
AC
MECHANICAL DATA :
* Case : Reliable low cost construction
utilizing molded plastic technique
* Epoxy : UL94V-O rate flame retardant
* Terminals : Plated lead solderable per
MIL-STD-202, Method 208 guaranteed
* Polarity : Polarity symbols marked on case
* Mounting position : Any
* Weight : 3.6 grams
Rating at 25
擄
C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Dimension in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
RATING
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Current Tc = 50
擄
C
Peak Forward Surge Current Single half sine wave
Superimposed on rated load (JEDEC Method)
Current Squared Time at t < 8.3 ms.
Maximum Forward Voltage drop per Diode at I
F
= 3.0 Amps.
Maximum DC Reverse Current
Ta = 25
擄
C
at Rated DC Blocking Voltage
Ta = 100
擄
C
Maximum Reverse Recovery Time (Note 1)
Typical Thermal Resistance per diode (Note 2)
Operating Junction Temperature Range
Storage Temperature Range
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
It
V
F
I
R
I
R(H)
Trr
R
胃
JC
T
J
T
STG
2
FBR
600
50
35
50
FBR
601
100
70
100
FBR
602
200
140
200
FBR
604
400
280
400
6.0
150
64
1.3
10
1.0
FBR
606
600
420
600
FBR
608
800
560
800
FBR
610
1000
700
1000
UNIT
Volts
Volts
Volts
Amps.
Amps.
A S
Volts
碌
A
mA
2
150
8
250
- 50 to + 150
- 50 to + 150
500
ns
擄
C/W
擄
C
擄
C
Notes :
1 ) Measured with I
F
= 0.5 Amp., I
R
= 1 Amp., Irr = 0.25 Amp.
2 ) Thermal resistance from Junction to Case with units mounted on a 6" x 5.5" x0.11" ( 15 x 14 x 0.3 cm ) Al. plate.
UPDATE : APRIL 21, 1998
