COMPACT POWER RELAY
1 POLE鈥?0 A
(For Automotive Applications)
FBR-53 SERIES
s
FEATURES
q
q
q
q
Compact for high density packaging
High contact capability (40A continuous)
High temperature grade (-40藲C to 125藲C)
Contact arrangement Form U (form A)
s
ORDERING INFORMATION
[Example]
(a)
(b)
(c)
FBR53
(a)
ND 012
(b) (c)
-Y - ***
(d) (e)
Series Name
Contact Arrangement
Nominal Voltage
FBR-53 : FBR-53 Series
ND
09
10
12
Y
Nil
-HW
: Form U
: 9 VDC
: 10 VDC
: 12 VDC
: Silver Tin Oxide Alloy
: Standard
: High capacity
(d)
(e)
Contact Material
Custom designation
Note: The part number on the relay cover does not include 'FBR'
Example:
Ordering part number: FBR-53ND12-Y
Stamped part number: 53ND12-Y
