FAN8024ED 4-Channel Motor Driver
September 2005
4-Channel Motor Driver
Features
鈥?2-Channel BTL driver with current feedback
鈥?2-Channel BTL DC motor driver
鈥?Built-in thermal shutdown circuit
鈥?Built-in mute circuit
鈥?Operating supply voltage: 4.5~13.2V
FAN8024ED
Description
The FAN8024ED is a monolithic IC, suitable for 2-ch BTL
DC motor drivers and 2-ch motor drivers with current
feedback which drive the focus and tracking actuators of
a CD media system.
28-SSOPH-375
Typical Applications
鈥?Compact disk ROM (CD-ROM)
鈥?Compact disk RW (CD-RW)
鈥?Digital video disk ROM (DVD-ROM)
鈥?Digital video disk RAM (DVD-RAM)
鈥?Digital video disk player (DVDP)
鈥?Other compact disk media
FAN8024ED
FAN8024EDTF
28-SSOPH-375
28-SSOPH-375
Ordering Information
Device
Package
Operating
Temp.
-25
擄C
~ 85
擄C
-25
擄C
~ 85
擄C
TF: Tape & Reel type
漏2005 Fairchild Semiconductor Corporation
1
www.fairchildsemi.com
FAN8024ED Rev. 1.0.0
