www.fairchildsemi.com

FAN5063

ACPI Dual Switch Controller

Features

鈥?Implements ACPI control with PWROK, SLP_S3 and

SLP_S5

鈥?Switch and linear regulator controller for 3.3V Dual (PCI)

鈥?Linear regulator controller and linear regulator for VADJ

Dual output adjustable from 2.5V to 3.5V

鈥?Break-before-Make

鈥?Drives all N-Channel MOSFETs plus NPN

鈥?Latched overcurrent protection for outputs

鈥?Power-up softstarts for the linear regulators

鈥?UVLO guarantees correct operation for all conditions

鈥?16 pin SOIC package

Description

The FAN5063 is an ACPI Switch Controller for the Camino,

Whitney and Tehama Platforms. It is controlled by PWROK,

SLP_S3 and SLP_S5, and provides 3.3V Dual for PCI and

VADJ Dual output for SDRAM or RAMBUS with 200mA

minimum base current for an external NPN transistor. An on-

board precision low TC reference achieves tight tolerance volt-

age regulation without expensive external components. The

FAN5063 also offers integrated Current Limiting that protects

each output, and softstart for the linear regulators. The

FAN5063 is available in a 16 pin SOIC.

Applications

鈥?Camino Platform ACPI Controller

鈥?Whitney Platform ACPI Controller

鈥?Tehama Platform ACPI Controller

Block Diagram

+5V Standby

PWR_OK

9

SLP_S3

7

SLP_S5

8

3

1

2

16

+12V

10

Softstart

Osc

+5V Main

15

Over Current

+3.3V Main

4

14

-

+

VADJ Dual

(2.5V RAMBUS

or 3.3V SDRAM)

13

+

-

REF

-

+

11

+

-

REF

5

6

+5V Standby

12

REF

+3.3V Dual (PCI)

REV. 1.0.0 12/4/00
