EL7630
Data Sheet
June 28, 2005
FN7371.0
White LED Boost Regulator
The EL7630 represents a high efficiency, constant frequency
PWM regulator for use in white LED driving applications.
With efficiencies up to 86%, the EL7630 operates at 1.35MHz
switching frequency while operating from an input voltage of
between 2.7V and 5.5V. The maximum output voltage of 27V
enables the EL7630 to drive up to 6 LEDs in series. It is also
possible to use the EL7630 to drive LEDs in series/parallel
combination for applications requiring up to 15 LEDs.
Available in the 6-pin SC-70 and the 5-pin TSOT packages,
the EL7630 features the same pinout as competitive
products but offers higher efficiency, constant frequency
operation. It is specified for operation over the -40擄C to
+85擄C ambient temperature range.
Features
鈥?Up to 6 LEDs in series
鈥?27V maximum output
鈥?2.7V to 5.5V input
鈥?Up to 86% efficient
鈥?1.35MHz constant frequency
鈥?Enable/PWM dimming control
鈥?Pb-Free plus anneal available (RoHS compliant)
Applications
鈥?LED backlighting
鈥?Cell phones
鈥?PDAs
Pinouts
EL7630
(6-PIN SC-70)
TOP VIEW
LX 1
GND 2
FB 3
6 VIN
5 PGND
4 ENAB
鈥?Handheld devices
Ordering Information
PART NUMBER
(See Note)
EL7630ICZ
EL7630ICZ-T7
PACKAGE
(Pb-free)
6-Pin SC-70
6-Pin SC-70
6-Pin SC-70
5-Pin TSOT
5-Pin TSOT
5-Pin TSOT
TAPE &
REEL
-
7鈥?/div>
(3K pcs)
7鈥?/div>
(250 pcs)
-
7鈥?/div>
(3K pcs)
7鈥?/div>
(250 pcs)
PKG. DWG. #
P6.049
P6.049
P6.049
MDP0049
MDP0049
MDP0049
EL7630
(5-PIN TSOT)
TOP VIEW
LX 1
GND 2
FB 3
4 ENAB
5 VIN
EL7630ICZ-T7A
EL7630IWTZ
EL7630IWTZ-T7
EL7630IWTZ-T7A
NOTE: Intersil Pb-free plus anneal products employ special Pb-free
material sets; molding compounds/die attach materials and 100%
matte tin plate termination finish, which are RoHS compliant and
compatible with both SnPb and Pb-free soldering operations. Intersil
Pb-free products are MSL classified at Pb-free peak reflow
temperatures that meet or exceed the Pb-free requirements of
IPC/JEDEC J STD-020.
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 1-888-468-3774
|
Intersil (and design) is a registered trademark of Intersil Americas Inc.
Copyright Intersil Americas Inc. 2005. All Rights Reserved
All other trademarks mentioned are the property of their respective owners.
