eCOG1 Microcontroller

Low Power Communications Processor

PRELIMINARY

The eCOG1 microcontroller is a low-power microcontroller based on a 16-bit Harvard architecture

with a 24-bit word code linear address space (32Mbyte) and 16-bit word linear data address

space (128Kbytes). It is available in a 128-pin LQFP with or without the IntAct high-speed serial

interface. A comprehensive toolset and C Compiler are available.

鈾?/div>

ChA

0 to 25MHz 3.3V processor

Powerful arithmetic operations

Barrel Shifter

Harvard Architecture

64Kx16 Data Memory

16Mx16 Program Memory

Built in Emulator (eICE)

Low power operation

64Kbytes FLASH EPROM

4Kbytes SRAM

MMU

Power-saving code cache

Code security feature

External Host Interface

External Memory Interface

Fast Vectored Interrupts

Dual UART

Dual USART

Smart Card Interface

SPI

I2C

Consumer IR/IRDA

4 channel 12-bit A/D

Parallel Interface

ChB

Stream

Down

鈾?/div>

5 Multi Purpose Timers

Watchdog Timer

Long Interval Timer

Real Time Clock

PWM timers

Temperature Sensor

Supply Voltage Sensor

Power-On Reset

General Purpose I/O

25MHz from watch XTAL

Interfaces to 8/16/32-bit parts

USART/SPI/IR

/IrDA/I2C/

Smart Card IF

Dual

UART

4KBytes

iRAM

IntAct

EHI

Data

Control

PWM

Switching Multiplexer

EMI

24 Bit

Addr/Data

8 Bit Data

12 Bit

ADC

Vdd

Sensor

MUX

Temp

Sensor

Vin

PIF

64K

Bytes

Flash

EPROM

16/32 Bit

Interface

MMU

GPIO

29 Bit I/O

or Control

Power

Reset

Interupt

Requests

Block

Code

Cache

System

Clock

Timers

External

Triggers

Clock Inputs

IRC

eCOG1

CPU Core

eICE

eICE_miso

eICE_mosi

eICE_Clock

eICE_Load#

eICE_CS

Reset_In

Figure 1 鈥?Internal Block Diagram

This document describes a device that is currently at pre-production status. Some specifications or descriptions may change.

V3.1

www.cyantechnology.com

1-Mar-2002
