PRODUCTION DATA SHEET
ECG040
DC - 4000 MHz
HIGH LINEARITY BROADBAND AMPLIFIER
Features
DC to 4000 MHz
14.8 dB Gain at 1000 MHz
18.0 dBm Output P1dB at 1000 MHz
35.0 dBm Output IP3 at 1000 MHz
Low Cost (Version)
Applications
Broadband Gain Blocks
High Linearity Amplifiers
Packages Available
(-B) SOT-89
(-C) 85 Mil Micro-X
Description
The ECG-040 is a high reliability, low cost broadband amplifier, optimized for commercial communications. The device is
manufactured using in-house developed, advanced Indium Gallium Phosphide Heterojunction Bipolar Transistor (InGaP
HBT) technology and is designed for use as a 50 Ohm gain block. The amplifier features excellent input/output return loss,
low noise figure and highly linear performance. Typical OIP3 is +35dBm at 1000MHz. The ECG-040 operates from a single
voltage supply and requires only two DC-blocking capacitors, a bias resistor and an inductor for operation. The device is
ideal for wireless applications and is available in a low cost, surface-mountable plastic 85 mil Micro-X and SOT-89 packages.
Electrical Specifications
Test Conditions: Ic = 70 mA, Ta = 25 C
SYMBOL
F
PARAMETER
Frequency
f
f
f
f
f
= 100MHz
= 1000MHz
= 2000MHz
= 3000MHz
= 4000MHz
o
MIN.
DC
LIMITS
TYP.
14.7
14.8
13.5
12.8
11.8
18.0
19.0
35.0
20.0
24.0
5.5
70.0
4.8
179.0
MAX.
4000
UNIT
MHz
TEST CONDITION
G
Gain (Small Signal)
dB
P1
dB
P
sat
OIP3
RL
in
RL
NF
Ic
Vde
c
胃
j
out
Output Power @ 1dB
Com pres s ion (70m A 25擄C)
Saturated Output Power
Output Third Order Intercept
Input Return Los s , 50 Ohm
Output Return Los s , 50 Ohm
Nois e Figure
Device Current
Device Voltage
Therm al Res is tance
f = 1000MHz
f = 1000MHz
f = 1000MHz
f = 1000MHz
f = 1000MHz
f = 1000MHz
dBm
dBm
dBm
dB
dB
dB
mA
V
Note 1
擄C/W
Note 1: OIP3 = Pout (by power m eter, total 2-tone power) + (IM3(dB))/2) - 3dB
CAUTION!
SENSITIVE ELECTRONIC DEVICE
EiC
Corp.
A Subsidiary of
EiC
Enterprises, Ltd.
45738 Northport Loop West, Fremont, CA 94538
Phone: (510) 979-8999
www.eiccorp.com
Fax: (510) 979-8902
SS-000530-000 Rev C
1
