PRODUCTION DATA SHEET
ECG009
DC - 2500 MHz
BROADBAND HIGH OIP3 AMPLIFIER
Features
DC to 2500 MHz
41 dBm Typical OIP3 at 1900 MHz
Highly Reliable InGaP HBT
19.0 dB Typical Gain at 900 MHz
24.0 dBm Typical P1dB at 1900 MHz
24.0 dBm Typical P1dB at 2170 MHz
5.7dB Typical noise figure at 900MHz
Excellent Stability
Applications
Multi-carrier Systems
High Linearity Amplifiers
Cellular, PCS, WLL
Package Available
(-B) SOT-89
Package
Description
The ECG009 is a high reliability, high OIP3 amplifier in a low
cost SOT-89 package, optimized for the commercial
communications market. The device is manufactured using
advanced Indium Gallium Phosphide Heterojunction Bipolar
Transistor (InGaP HBT) technology. The amplifier can be
matched to achieve low VSWR and high OIP3 over the DC to
2500 MHz range. Typical OIP3 at 1900 MHz is +41 dBm. The
ECG009 operates from a single 5 volt power supply.
RF in
Gnd
RFout
Gnd
SOT-89 (Top View)
Electrical Specifications
Test Conditions: Ta = 25 C, V = 5.0 V
SYMBOL
F
G
Frequency
Gain (Sm all Signal)
Output Power @ 1 dB
Com pres s ion
Output Third Order Intercept
f = 900 MHz
f = 1900 MHz
f = 2170 MHz
f = 900 MHz
f = 1900 MHz
f = 2170 MHz
f = 900 MHz
f = 1900 MHz
f = 2170 MHz
f = 900 MHz
f = 1900 MHz
f = 2170 MHz
f = .9 to 2.5 GHz
f = 900 MHz
f = 1900 MHz
130
15.0
PARAMETER
o
LIMITS
MIN.
DC
13.5
12.5
19.0
14.5
13.5
24
24
24
41
41
40
8.0
9.0
20.0
12.0
5.7
6.5
150
10:1
86
170
TYP.
MAX.
2500
UNIT
MHz
dB
TEST CONDITION
P
1dB
dBm
OIP3
39.5
38.5
dBm
Note 1
RL
RL
RL
NF
I
c
c
胃
j
IN
Input Return Los s , 50 Ohm
Input Return Los s , 50 Ohm
Output Return Los s , 50 Ohm
Nois e Figure
Supply Current
Output Mis m atch without Spurs
Therm al Res is tance
dB
dB
dB
dB
mA
Note 2
IN
OUT
擄C/W
Note 1: OIP3 = Pout (by power m eter, total 2-tone power) + (IM3 (dBc)) / 2 - 3 dB
EiC
Corp.
A Subsidiary of
EiC
Enterprises, Ltd.
45738 Northport Loop West, Fremont, CA 94538
Phone: (510) 979-8999
www.eiccorp.com
Fax: (510) 979-8902
SS-000346-000 Rev E
1
