PRELIMINARY DATA SHEET
ECG001
DC - 6000 MHz
HIGH LINEARITY BROADBAND AMPLIFIER
Features
DC to 6000 MHz
20.0 dB Gain at 1000 MHz
12.5 dBm Output P1dB at 1000 MHz
25 dBm Output IP3 at 1000 MHz
3.7 dB Noise Figure at 2000 MHz
Applications
Broadband Gain Blocks
High Linearity Amplifiers
Packages Available
(-B) SOT-89
(-C) 85 Mil Micro-X
(-F) SOT-363
Description
The ECG001 is a high reliability, high linearity, low cost broadband amplifier, optimized for commercial communications.
The device is manufactured using in-house developed, advanced Indium Gallium Phosphide Heterojunction Bipolar Transistor
(InGaP HBT) technology and is designed for use as a 50 Ohm gain block. The amplifier features excellent VSWR, low noise
figure and highly linear performance. Typical OIP3 is +25dBm at 1000 MHz. The ECG001 operates from a single voltage
supply and requires only two DC-blocking capacitors, a bias resistor and an inductor for operation. The device is ideal for
wireless applications and is available in a low cost, surface-mountable plastic 85 mil Micro-X and SOT-89 packages. The
ECG001 is designed in the Darlington configuration with direct feedback. Its operation frequency at low end is limited only
by the DC blocking capacitor and the RF choke inductor (large values are required in both cases).
Electrical Specifications
Test Conditions: Ic= 30mA Ta = 25 C,
SYMBOL
F
G
PARAMETER
Frequency
Gain (Small Signal)
f
f
f
f
f
f
f
f
f
f
= 1000MHz
= 2000MHz
= 3000MHz
= 6000MHz
= 1000MHz
= 2000MHz
= 3000MHz
= 1000MHz
= 2000MHz
= 3000MHz
o
MIN.
DC
17.0
17.0
14.5
LIMITS
TYP.
20.0
19.0
18.0
13.0
17.0
12.5
12.5
12.6
25.0
26.0
26.0
14.0
18.0
3.7
MAX.
6000
UNIT
MHz
dB
TEST CONDITION
G
P
1dB
Gain(Large signal) Pin=-4.5dBm
Output Power @ 1dB
Compression
Output Third Order Intercept
Input Return Loss, 50 Ohm
Output Return Loss, 50 Ohm
Noise Figure
Device Voltage
f = 3000MHz
dB
dBm
OIP3
RL
in
RL
out
NF
Vde
dBm
dB
dB
dB
3.8
V
Note 1
f = 2000MHz
f = 2000MHz
f = 2000MHz
3.0
3.4
Note 1: OIP3 = Pout (by power meter, total 2-tone power) + (IM3(dB))/2) - 3dB
CAUTION!
SENSITIVE ELECTRONIC DEVICE
EiC
Corp.
A Subsidiary of
EiC
Enterprises, Ltd.
45738 Northport Loop West, Fremont, CA 94538
Phone: (510) 979-8999
www.eiccorp.com
Fax: (510) 979-8902
SS-000349-000 Rev G
1
