EC1089
Product Features
x
x
x
x
x
x
10 鈥?2500 MHz
+24 dBm P1dB
+41 dBm OIP3
15.5 dB Gain at 900 MHz
12.2 dB Gain at 1900 MHz
Available in SOT-89 and
lead-free / green SOT-89
Package Styles
x
Internally matched to 50
:
The Communications Edge
TM
Product Information
InGaP HBT Gain Block
Product Description
The EC1089 is a high dynamic range driver amplifier in a
low-cost surface mount package. The InGaP/GaAs HBT is
able to achieve high performance across a broad range with
+41 dBm OIP3 and +24 dBm of compressed 1dB power. It
is housed in an industry standard SOT-89 SMT package.
The EC1089 is also available in a lead-free/green/RoHS-
compliant SOT-89 package. All devices are 100% RF and
DC tested.
The EC1089 is targeted for use as a driver amplifier in
wireless infrastructure where high linearity and medium
power is required. An internal active bias allows the
EC1089 to maintain high linearity over temperature and
operate directly off a single +5 V supply. This combination
makes the device an excellent candidate for transceiver line
cards in current and next generation multi-carrier 3G base
stations.
Functional Diagram
GND
4
1
RF IN
2
GND
3
RF OUT
EC1089B / EC1089B-G
Applications
x
Mobile Infrastructure
x
Final stage amplifiers for
Repeaters
x
Defense / Homeland Security
Specifications
(1)
Parameters
Operational Bandwidth
Test Frequency
Gain
Input Return Loss
Output Return Loss
Output P1dB
Output IP3
(2)
IS-95A Channel Power
@ -45 dBc ACPR
Typical Performance
(3)
Units
MHz
MHz
dB
dB
dB
dBm
dBm
dBm
dB
MHz
dB
dBm
dBm
mA
V
Min
10
10.5
Typ
1900
12.2
15
10
+23.5
+41
+17
5.9
2140
11.5
+23.5
+40
160
+5
Max
2500
Parameters
Frequency
S21 - Gain
S11 - Input R.L.
S22 - Output R.L.
Output P1dB
Output IP3
Noise Figure
Supply Bias
隆
Units
MHz
dB
dB
dB
dBm
dBm
dB
Typical
900
1900
2140
15.5
12.2
11.5
-14
-15
-15
-10
-10
-10
+24
+23.5
+23.5
+40
+41
+40
5.1
5.9
5.4
+5 V @ 160 mA
+40
Noise Figure
Test Frequency
Gain
Output P1dB
Output IP3
(2)
Operating Current Range
Device Voltage
3. Typical parameters reflect performance in a tuned application circuit: Supply Voltage = +5 V, I =
160 mA, +25 C
140
175
1. Test conditions unless otherwise noted: 25潞 C, Supply Voltage = +5 V, , in tuned application circuit.
2. 3OIP measured with two tones at an output power of +11 dBm/tone separated by 1 MHz. The
suppression on the largest IM3 product is used to calculate the 3OIP using a 2:1 rule.
Absolute Maximum Rating
Operating Case Temperature
Storage Temperature
RF Input Power (continuous)
Device Voltage
Device Current
Junction Temperature
Ordering Information
Part No.
EC1089B
EC1089B-G
EC1089B-PCB900
EC1089B-PCB1900
EC1089B-PCB2140
Parameter
-40 to +85
qC
-65 to +150
qC
+18 dBm
+6 V
220 mA
+250
qC
Rating
Description
(leaded SOT-89 Pkg)
InGaP HBT Gain Block
InGaP HBT Gain Block
(lead-free/green/RoHS-compliant SOT-89 Pkg)
900 MHz Evaluation Board
1900 MHz Evaluation Board
2140 MHz Evaluation Board
Operation of this device above any of these parameters may cause permanent damage.
Specifications and information are subject to change without notice
聽
聽
聽
聽
WJ Communications, Inc
Phone 1-800-WJ1-4401
FAX: 408-577-6621
e-mail: sales@wj.com
Web site: www.wj.com
December 2004
