E846-EDGE846 Datasheet

  • E846-EDGE846

  • Pin Electronics Driver. Window Comparator. and Switch Matrix

  • 100.84KB

  • 14頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Edge846
Pin Electronics Driver, Window
Comparator, and Switch Matrix
TEST AND MEASUREMENT PRODUCTS
Description
The Edge846 is an integrated trinary driver, window
comparator, and switch matrix pin electronics solution
manufactured in a wide voltage CMOS process. It is
designed for automatic test equipment and
instrumentation where cost, functional density, and power
are all at a premium.
The tristatable driver is capable of generating 3 levels -
one for a logic high, one for a logic low, and one for either
a termination voltage or a special programming voltage.
The on-board window comparator effectively determines
whether the DUT is in a high, low, or intermediate state.
The switches are included to allow such functions as PMU,
pull-up, and pull-down connections.
The Edge846 is intended to offer an extremely low leakage,
low cost, low power, highly integrated, per pin solution
for 50 MHz and below pin electronics applications.
DATA
DOUT
DVR EN*
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
50 MHz Operation
18 V DUT I/O Range
Programmable Output Levels
Programmable Input Thresholds
Three Level Driver
Extremely Low Leakage Currents (<5 nA)
Small Footprint (32 Pin, 7 mm X 7 mm,
TQFP Package)
Functional Block Diagram
VH VTT VL
Applications
鈥?/div>
Low Cost ATE
VTT EN
SW3
SW3 EN*
SW0
KSW0
SW0 EN*
SW1
KSW1
SW1 EN*
SW2
KSW2
SW2 EN*
LOAD1
LOAD0
COMPA
CVA
VINP
COMPB
CVB
Revision 2 / October 21, 2002
1
www .semtech.com
