E712545 Datasheet

  • E712545

  • 8-bit Proprietary Microcontroller

  • 520.02KB

  • 48頁

  • FUJITSU   FUJITSU

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

FUJITSU SEMICONDUCTOR
DATA SHEET
DS07-12545-1E
8-bit Proprietary Microcontroller
CMOS
F
2
MC-8L MB89960 Series
MB89965/P965A/F969A/
MB89PV960
s
DESCRIPTION
The MB89960 series is a single-chip microcontroller that utilizes the F
2
MC-8L core for low voltage and high speed
performance. The microcontroller contains a range of peripheral functions including timers, a serial interface, I
2
C
interface, A/D converter, and external interrupts. The internal I
2
C interface complies with the SM bus standard
and supports an SM bus battery controller.
s
FEATURES
鈥?Range of package options
鈥?QFP and MQFP packages (0.8 mm pitch)
鈥?LQFP package (0.5 mm and 0.65 mm pitch)
鈥?/div>
High speed operation at low voltage
Minimum instruction execution time
=
0.4
碌s
(for a 10 MHz oscillation)
鈥?/div>
F
2
MC-8L CPU core
Instruction set optimized for controller applications
鈥?Multiplication and division instructions
鈥?16-bit arithmetic operations
鈥?Bit test branch instructions
鈥?Bit manipulation instructions, etc.
鈥?/div>
Dual-clock control system
鈥?Main clock : 10 MHz max.
(Four speed settings available, oscillation halts in sub-clock mode)
鈥?Sub-clock : 32.768 kHz (Operation clock for sub-clock mode)
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Four channels
8/16-bit timer/counter (8-bit
脳
2 channels or 16-bit
脳
1 channel)
21-bit timebase timer
Clock prescaler (15-bit)
鈥?/div>
Serial I/O
Selectable transfer format (MSB-first or LSB-first) supports communications with a wide range of devices.
鈥?/div>
A/D converter
10-bit
脳
4 channels
