PF1038-02
E0C63455
4-bit Single Chip Microcomputer
q
4-bit E0C63000 Core CPU
q
Built-in Dot-matrix LCD Driver
q
High Speed Instruction Cycle (2-6CPI)
s
DESCRIPTION
The E0C63455 is a CMOS 4-bit microcomputer composed of a CMOS 4-bit core CPU, ROM, RAM, dot-matrix
type LCD driver, serial interface and counters. And the E0C63455 can be operated with high speed and spend
little current.
s
FEATURES
q
CMOS LSI 4-bit parallel processing ..... E0C63000 core CPU
q
Main clock ............................................. 32.768kHz (Typ.) crystal / 60kHz (Typ.) CR
q
Sub clock .............................................. 1.8MHz (Typ.) CR / 4MHz (Max.) ceramic
q
Instruction set ........................................ 46 types (411 instructions with all), 8 typs addressing mode
q
Instruction execution time ..................... 32.768kHz
4MHz
q
ROM capacity ....................................... Code ROM
Data ROM
: 61碌sec,
: 0.5碌sec,
122碌sec, 183碌sec
1.0碌sec, 1.5碌sec
: 4,096 words
脳
13 bits
: 2,048 words
脳
4 bits
q
RAM capacity ........................................ Data memory
: 1,024 words
脳
4 bits
Display memory : 480 bits (120 words
脳
4 bits)
q
I/O port .................................................. I : 4 bits (Pull-up resistors may be supplemented)
O : 4 bits (It is possible to switch the 2 bits to special output)
I/O : 8 bits (It is possible to switch the 4 bits to serial I/F input/output)
q
LCD driver ............................................. 60 segments
脳
8 commons
q
Clock timer ............................................ 1 ch.
q
Stopwatch timer .................................... 1 ch.
q
Programmable timer ............................. 8 bits
脳
2 ch.
q
Watchdog timer ..................................... Built-in
q
Serial interface ...................................... 8-bit clock synchronous
q
Sound generator ................................... With envelope and 1-shot output functions
q
Interrupts ............................................... External : Kye interrupt
Internal : Clock timer interrupt
: Stopwatch timer interrupt
: Programmable timer interrupt
: Serial interface interrupt
q
Operating temperature range ............... -20擄C to 70擄C
q
Current consumption ............................ 1.0碌A(chǔ) (32.768kHz, LCD OFF, 3.0V, HALT)
4.0碌A(chǔ) (32.768kHz, LCD ON, 3.0V, RUN)
1,000碌A(chǔ) (4MHz, LCD ON, 3.0V, RUN)
q
Package ................................................ QFP5-128pin / QFP8-128pin (plastic), Die form
1 system
4 systems
2 systems
2 systems
1 system
q
Power supply voltage ............................ 2.2 to 6.4V (Min. 1.8V with OSC1 crystal oscillation circuit only)
