Broadband Eight-Way Power Divider
20 - 2000 MHz
Features
q
q
q
DS-808-4
V2.00
C-18
Two-Decade Frequency Range
High Isolation 鈥?20 dB Min
Typical Midband VSWR 1.2:1
Guaranteed Speci鏗乧ations*
1.4 dB Max
Dimensions in ( ) are in mm.
Unless Otherwise Noted: .xxx = 鹵0.015 (.x = 鹵0.4)
Weight (Approx): 9 Ounces 255 Grams
Operating Characteristics
MIL-STD-883 screening available.
*All speci鏗乧ations apply with 50 ohm source and load impedance.
This product contains elements protected by United States Patent Number
3,325,587.
Ordering Information
Model No.
DS-808-4 BNC
DS-808-4 SMA
DS-808-4 TNC
DS-808-4 N
Package
Connectorized
Connectorized
Connectorized
Connectorized
M/A-COM Division of AMP Incorporated
s
North America: Tel. (800) 366-2266, Fax (800) 618-8883
s
Asia/Paci鏗乧: Tel. +85 2 2111 8088, Fax +85 2 2111 8087
s
Europe: Tel. +44 (1344) 869 595, Fax +44 (1344) 300 020
6-42
www.macom.com
AMP and Connecting at a Higher Level are trademarks.
Speci鏗乧ations subject to change without notice.
6-42
