Small Size and Low Profile
Industry Standard SOIC-8 SMT Plastic Package
Excellent Amplitude and Phase Balance
Superior Repeatability
Typical Insertion Loss 0.4 dB
Typical Isolation 20 dB
1 Watt Power Handling
Frequency Coverage for GPS and LEO Programs
SOIC-8
Description
M/A-COM鈥檚 DS52-0004 is an IC-based monolithic power
divider in a low cost SOIC-8 plastic package. This 2-way power
divider is ideally suited for applications where small size, low
insertion loss, superior phase/amplitude tracking and low cost
are required. Typical applications include base station switching
networks and other communication applications where size and
PCB real estate are a premium. Available in tape and reel.
The DS52-0004 is fabricated using a passive-integrated circuit
process. The process features full-chip passivation for increased
performance and reliability.
Ordering Information
Part Number
DS52-0004
DS52-0004-TR
DS52-0004-RTR
Package
SOIC-8 Lead Plastic Package
Forward Tape and Reel
1
Reverse Tape and Reel
1
1. If specific reel size is required, consult factory for part number
assignment.
Typical Electrical Specifications
1
, T
A
= +25擄C
Parameter
Insertion Loss
Isolation
VSWR
Input RL
VSWR
Output RL
Amplitude Balance
Phase Balance
Above 3.0dB
Units
dB
dB
鈥?/div>
鈥?/div>
dB
擄
Min
鈥?/div>
15
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Typ
0.4
20
1.3:1
1.4:1
0.1
1.0
Max
0.6
鈥?/div>
1.5:1
1.6:1
0.2
3.0
1. All specifications apply with a 50-Ohm source and load impedance.
Specifications subject to change without notice.
V 2.0
North America:
Tel. (800) 366-2266, Fax (800) 618-8883
Asia/Pacific:
Tel.+81-44-844-8296, Fax +81-44-844-8298
Europe:
Tel. +44 (1344) 869 595, Fax+44 (1344) 300 020
Visit www.macom.com for additional data sheets and product information.
1
