Low Cost Two-Way SMT Power Splitter/Combiner
DS52-0003
2200 - 2500 MHz
V4.00
Features
q
q
q
q
q
q
q
SO-8
PIN 8
.1497-.1574
(3.80-4.00)
-B-
.2284-.2440
(5.80-6.20)
.010(0.25) M B M
Small Size, Low Pro鏗乴e and Low Cost
Industry Standard SOIC-8 SMT Plastic Package
Superior Repeatability
Excellent Amplitude Balance: 0.05 dB Typical
Excellent Insertion Loss: 0.3 dB Typical
Low Cost
Wireless Data Frequency Coverage
Orientation
mark
PIN 1
.1890-.1968
(4.80-5.00)
-A-
.004 (0.10)
.0532-.0688
(1.35-1.75)
0擄-8擄
-C-
.0040-.0098
(0.10-0.25)
.013-.020 TYP.
(0.33-0.51)
.0099-0.0196
x 45擄 Chamfer
(0.25-0.50)
.016-.050
(0.40-1.27)
.0075-0.0098
(0.19-0.25)
Description
M/A-COM鈥檚 DS52-0003 is an IC based monolithic power
splitter in a low cost SOIC-8 plastic package. This 2-way
device is ideally suited for applications where small size,
low profile and low cost, without sacrificing
performance, are required. Typical applications include
base station, portables and PCMCIA cards for wireless
data and spread spectrum applications. Available in tape
and reel.
The DS52-0003 is fabricated using a passive-integrated
circuit process. The process features full chip passivation
for increased performance and reliability.
.050(1.27) BSC.
.010(0.25) M C A M B S
8- Lead SOP outline dimensions
Narrow body .150
(All dimensions per JEDEC No. MS-012-AA, Issue C)
Dimensions in ( ) are in mm.
Unless Otherwise Noted: .xxx = 鹵 0.010 (.xx = 鹵 0.25)
.xx = 鹵 0.02 (.x = 鹵0.5)
Ordering Information
Part Number
DS52-0003
DS52-0003-TR
DS52-0003-RTR
Package
SOIC 8-Lead Plastic Package
Forward Tape and Reel*
Reverse Tape and Reel*
* If speci鏗乧 reel size is required, consult factory for part number
assignment.
Typical Electrical Speci鏗乧ations
1
,
T
A
= +25擄C
Parameter
Insertion Loss Above 3.0 dB
Isolation
VSWR
Amplitude Balance
Phase Balance
1. All speci鏗乧ations apply with a 50-ohm source and load impedance.
Units
dB
dB
dB
擄
Min.
15
Typ.
0.3
20
1.3:1
0.05
3
Max.
0.5
1.5:1
0.1
5
Speci鏗乧ations Subject to Change Without Notice.
M/A-COM, Inc.
North America:
Tel. (800) 366-2266
Fax (800) 618-8883
s
1
Asia/Paci鏗乧: Tel. +81 (03) 3226-1671
Fax +81 (03) 3226-1451
s
Europe: Tel. +44 (1344) 869 595
Fax +44 (1344) 300 020
