DS3160 Datasheet

  • DS3160

  • JT 6312kbps Secondary-Rate Line Interface Unit and Framer/Fo...

  • 558.70KB

  • 107頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DS3160
JT 6312kbps Secondary-Rate
Line Interface Unit
and Framer/Formatter
www.maxim-ic.com
FEATURES
摟
摟
摟
摟
摟
摟
摟
摟
摟
摟
摟
Single-chip JT 6312kbps secondary-rate line
interface unit (LIU) and framer/formatter
Supports G.704 and NTT J2 frame formats
Transmit and receive path-monitor outputs
B8ZS encoder and decoder
Generates and detects alarms
Integrated HDLC controller handles LAPD
messages without host intervention
Integrated BERT supports performance
monitoring
Supports 8-bit or 16-bit control
3.3V supply with 5V tolerant I/O; low-power
CMOS
Available in 100-pin LQFP package
IEEE 1149.1 JTAG support
FUNCTIONAL DIAGRAM
LINE
INTERFACE
UNIT
FRAMER
AND
FORMATTER
CONTROL AND STATUS PORT
APPLICATIONS
摟
摟
摟
摟
摟
摟
Routers
Switches
Test Equipment
Aggregators/Concentrators
PBX
Base Stations
ORDERING INFORMATION
DS3160
100-pin LFQP
0擄C to +70擄C
DS3160C01 100-pin LFQP
0擄C to +85擄C
DS3160N
100-pin LFQP -40擄C to +85擄C
DESCRIPTION
The DS3160 device, which combines a line interface unit (LIU) with a formatter and framer, is compliant
with the JT 6312kbps secondary-rate user-network interface and supports the G.704 and NTT J2 frame
formats. A full-featured LIU with integrated jitter attenuator supports a software-programmable framer
and formatter. Framer features include alarm and error detection, on-chip HDLC controller for processing
of M-bit information, and programmable timeslot data-enable signal for 1.5Mbps, 3Mbps, 4.5Mbps, and
6Mbps frame formats. The formatter adds the required overhead to the user data and has the additional
capability of generating diagnostic errors. Loopback features, together with an on-chip bit-error-rate test
(BERT) function, allow easy isolation and monitoring of network segments.
Note:
Some revisions of this device may incorporate deviations from published specifications known as errata. Multiple
revisions of any device may be simultaneously available through various sales channels. For information about device errata,
click here:
http://www.maxim-ic.com/errata.
1 of 107
062102
