DS2433S/TR Datasheet

  • DS2433S/TR

  • EEPROM

  • 21頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

PRELIMINARY
www.dalsemi.com
DS2433
4kb 1-Wire EEPROM
PIN ASSIGNMENT
PR-35
FEATURES
摟
摟
4096 bits Electrically Erasable Programmable
Read-Only Memory (EEPROM)
Unique, factory-lasered and tested 64-bit
registration number (8-bit family code + 48-
bit serial number + 8-bit CRC tester) assures
absolute identity because no two parts are
alike
Built-in multidrop controller ensures
compatibility with other MicroLAN鈩?/div>
products
Memory partitioned into sixteen 256-bit pages
for packetizing data
256-bit scratchpad with strict read/write
protocols ensures integrity of data transfer
Reduces control, address, data, and power to a
single data pin
Directly connects to a single port pin of a
microprocessor and communicates at up to
16.3kbps
Overdrive mode boosts communication speed
to 142kps
8-bit family code specifies DS2433
communication requirements to reader
Presence detector acknowledges when reader
first applies voltage
Low cost PR-35 or 8-pin SO surface mount
package
Reads and writes over a wide voltage range of
2.8V to 6.0V from -40擄C to +85擄C
NC
NC
DATA
GND
1
2
3
4
8
7
6
5
NC
NC
NC
NC
摟
摟
摟
摟
摟
摟
摟
摟
摟
摟
8-Pin SO (208mil)
1 2
3
PR-35
1 2
3
BOTTOM VIEW
PIN DESCRIPTION
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5-8
PR-35
Ground
Data
NC
鈥?/div>
鈥?/div>
SO
NC
NC
Data
Ground
NC
ORDERING INFORMATION
DS2433
DS2433S
DS2433S/T&R
DS2433X
DS2433X-S
PR-35 package
8-pin SOIC package
Tape & Reel version of
DS2433S
Chip Scale Pkg., Tape &
Reel
Chip-Scale Pkg, 2.5k pc.,
Tape & Reel
SILICON LABEL DESCRIPTION
The DS2433 4kb 1-Wire
廬
EEPROM identifies and stores relevant information about the product to which
it is associated. This lot or product specific information can be accessed with minimal interface, for
example a single port pin of a microcontroller. The DS2433 consists of a factory-lasered registration
1-Wire is a registered trademark of Dallas Semiconductor.
MicroLAN is a trademark of Dallas Semiconductor.
1 of 21
080902
