DS21354DK Datasheet

  • DS21354DK

  • T1 Single-Chip Transceiver Design Kit Daughter Card

  • 20頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DS21354DK
T1 Single-Chip Transceiver
Design Kit Daughter Card
www.maxim-ic.com
GENERAL DESCRIPTION
The DS21354 design kit is an easy-to-use evaluation
board for the DS21354 E1 single-chip transceiver
(SCT). The DS21354DK is intended to be used as a
daughter card with either the DK2000 or the DK101
motherboards. The DS21354DK comes complete
with a DS21354 SCT, transformers, termination
resistors, configuration switches, line-protection
circuitry, network connectors, and motherboard
connectors. The DK101/DK2000 motherboard and
Dallas鈥?ChipView software give point-and-click
access to configuration and status registers from a
Windows芒-based PC. On-board LEDs indicate
receive loss-of-signal and interrupt status, as well as
multiple clock and signal routing configurations.
Each DS21354DK is shipped with a free DK101
motherboard. For complex applications, the DK2000
high-performance demo kit motherboard can be
purchased separately.
Windows is a registered trademark of Microsoft Corp.
FEATURES
摟
摟
摟
摟
摟
摟
摟
摟
摟
摟
摟
摟
Demonstrates Key Functions of the DS21354 E1
SCT Transceiver
Includes DS21354 SCT, Transformers, Bantum,
BNC and RJ48 Network Connectors, and
Termination Passives
BNC Connections for 75W E1
Bantam and RJ48 Connectors for 120W E1
Multitap
Transformer
to
Facilitate
True
Impedance Matching for 75W and 120W/100W
Paths
Compatible with DK101 and DK2000 Demo Kit
Motherboards
DK101/DK2000 and ChipView Software Provide
Point-and-Click Access to the DS21354 Register
Set
Software-Controlled (Register Mapped) Configuration
Switches to Facilitate Clock and Signal Routing
All Equipment-Side Framer Pins are Easily
Accessible for External Data Source/Sink
LEDs for Loss-Of-Signal and Interrupt Status as
well as Indications for Multiple Clock and Signal
Routing Configurations
Easy-to-Read Silk Screen Labels Identify the
Signals Associated with all Connectors, Jumper,
and LEDs
Network Interface Protection for Overvoltage and
Overcurrent Events Area Available for Further
Customization
DESIGN KIT CONTENTS
DS21354DK Design Kit Daughter Card
DK101 Low-Cost Motherboard
CD ROM
ChipView Software
DS21354DK Data Sheet
DK101 Data Sheet
DS21354 Data Sheet
DS21354 Errata Sheet
ORDERING INFORMATION
PART
DS21354DK
DESCRIPTION
DS21354 Design Kit Daughter Card
(with include DK101 motherboard)
1 of 20
REV: 011904

DS21354DK 產品屬性

  • Lead (SnPb) Finish for COTSObsolescence Mitigation Program

  • 1

  • 編程器，開發系統

  • 評估演示板和套件

  • -

  • 電信，調幀器和線路接口裝置（LIU）

  • -

  • DS21354

  • -

  • -

  • 板，子卡，CD
