DS21352DK Datasheet

  • DS21352DK

  • T1 Single-Chip Transceiver Design Kit Daughter Card

  • 1078.14KB

  • 20頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DS21352DK
T1 Single-Chip Transceiver
Design Kit Daughter Card
www.maxim-ic.com
GENERAL DESCRIPTION
The DS21352 design kit is an easy-to-use evaluation
board for the DS21352 T1 single-chip transceiver
(SCT). The DS21352DK is intended to be used as a
daughter card with either the DK2000 or the DK101
motherboards. The DS21352DK comes complete
with an SCT, transformers, termination resistors,
configuration switches, line-protection circuitry,
network connectors, and motherboard connectors.
The DK101/DK2000 motherboard and Dallas鈥?/div>
ChipView software give point-and-click access to
configuration and status registers from a Windows芒-
based PC. On-board LEDs indicate receive loss-of-
signal and interrupt status, as well as multiple clock
and signal routing configurations.
Each DS21352DK is shipped with a free DK101
motherboard. For complex applications, the DK2000
high-performance demo kit motherboard can be
purchased separately.
Windows is a registered trademark of Microsoft Corp.
FEATURES
摟
摟
摟
摟
摟
摟
摟
摟
摟
Demonstrates Key Functions of DS21352 T1
SCT Transceiver
Includes DS21352 SCT, Transformers, Bantum,
BNC and RJ48 Network Connectors, and
Termination Passives
Compatible with DK101 and DK2000 Demo Kit
Motherboards
DK101/DK2000 and ChipView Software Provide
Point-and-Click Access to the DS21352 Register
Set
Software-Controlled
(Register
Mapped)
Configuration Switches to Facilitate Clock and
Signal Routing
All Equipment-Side Framer Pins are Easily
Accessible for External Data Source/Sink
LEDs for Loss-Of-Signal and Interrupt Status as
well as Multiple Clock and Signal Routing
Configurations
Easy-to-Read Silk Screen Labels Identify the
Signals Associated with all Connectors, Jumpers
and LEDs
Network Interface Protection for Overvoltage and
Overcurrent Events
ORDERING INFORMATION
PART
DS21352DK
DESCRIPTION
DS21352 Design Kit Daughter Card
(with included DK101 motherboard)
DEMO KIT CONTENTS
DS21352DK Design Kit Daughter Card
DK101 Low-Cost Motherboard
CD ROM
ChipView Software
DS21352DK Data Sheet
DK101 Data Sheet
DS21352 Data Sheet
DS21352 Errata Sheet
1 of 20
REV: 011904
